elocation-id: e3613
The environment influences the chemical composition of plant essential oil and its biological effect. The purpose of the study was to describe the chemical profile of Tagetes lucida essential oil and to evaluate the in vitro biological effect against B. cinerea. The study was conducted in Texcoco, Mexico in October 2021. Essential oil was obtained from flowering plants by hydrodistillation; the identification of chemical compounds was carried out using the GC-MS technique. The in vitro bioassay employed the method of poisoned agar and mycelium of B. cinerea of three days of growth. Twelve treatments were evaluated: essential oil 0.1, 0.5, 1, and 2%, Tween 20 at 0.1, 0.3, 0.5, 0.8, 1 and 2%, commercial fungicide, and absolute control (only with sterile double-distilled water). Every 24 h, radial growth of the fungus was measured with a digital vernier and growth rate and inhibition of mycelial growth were estimated. Thirty-one chemical compounds were identified, (1S)-(-)-β-Pinene (36.4%), 1, 3, 5, 7-Cyclooctatetraene (12.7%), eucalyptol (10.6%), and o-Cymene (6.1%). The concentrations of 0.1, 0.5, 1 and 2% inhibited the mycelial growth and sporulation of B. cinerea. The commercial fungicide and the 2% concentration totally inhibited the growth of the fungus. Tween 20 also inhibited mycelial growth. The LC50 was 0.06% and the LC95 was 1.69%. The abundance of terpenes in the essential oil of T. lucida showed a fungicidal effect against B. cinerea. The surfactant had minor effects.
Tagetes lucida, B. cinerea, essential oil.
The Yiahutli, pericón, or Santa Maria herb (Tagetes lucida Cav.) is a plant distributed in temperate and transition zones, at altitudes of 1 400 to 2 800 m (Serrato, 2014), grows in pine, oak, pine-oak, and broadleaf forest vegetation (Turner, 1996). Its height is from 40 cm to 1.8 m and its flowering begins in mid-August until October (Serrato, 2014).
Current traditional knowledge about T. lucida reveals various uses: as a relaxant in cancer situations, cleaning of C-section wounds, remedy against scorpion and snake bites, to reduce rheumatic pain, control ticks in birds, soften the effect of hangovers, scent washed clothes, eliminate lice and flea eggs, make cane alcohol with anise flavor, and flavoring of various foods (Serrato, 2014). It has a biocidal effect against pathogens that affect humans (Céspedes et al., 2006; Torres-Martínez et al., 2022) and other biological effects against nematodes (Omer et al., 2015) and some phytopathogenic fungi (López et al., 2018).
All these effects are attributed to the chemical compounds contained in T. lucida, such as terpenoids, coumarins and flavonoids (Gutiérrez et al., 2018). Around 40 to 44 secondary metabolites of the class of monoterpenes, sesquiterpenes, and phenylpropanoids have been detected in the essential oil (Regalado et al., 2011; Zarate-Escobedo et al., 2018), which means a wide variability in types and quantity of molecules. In T. lucida essential oil, the abundance of monoterpenes and phenylpropanoids is related to climate and soil variability (Zárate-Escobedo et al., 2018).
Studies conducted with T. lucida essential oil against fungi used plant populations from cold temperate and semi-cold climates (Céspedes et al., 2006; Barajas et al., 2011; López et al., 2018), in which phenylpropanoids (anethole and estragole) are the main components and are responsible for biological effects against fungi.
T. lucida oil that has this origin inhibits mycelial growth, sporulation, and sclerotia formation in Sclerotium rolfsii and Monilinia fructicola (Barajas et al., 2011). It also inhibits the mycelial growth of Aspergillus niger, Fusarium oxysporum, Penicillium janthinellum, and Rhizoctonia solani (López et al., 2018). In hot weather, the secondary metabolites in the essential oil correspond mostly to terpenes (Zárate-Escobedo et al., 2018). Therefore, the evaluation of the biological effect of the essential oil of this species grown in warm temperate climates is important.
The variation in the chemical composition of essential oils depends on various factors, including genetic and environmental factors (Acero-Godoy et al., 2019). Therefore, toxicological studies with T. lucida oil should consider the characteristics of the habitat in which populations of this species develop naturally.
The evaluation of T. lucida terpenes in fungal growth will complement the available information on the fungal effects of phenylpropanoids contained in the same species grown in temperate environments of cold subtypes. The distribution of natural populations of T. lucida in altitudinal levels (Serrato, 2014), associated with contrasting temperatures, represents a rich environmental diversity for T. lucida and also of biomolecules.
Although several essential oils have been evaluated against B. cinerea (Tančinová et al., 2022), T. lucida essential oil has not yet been evaluated against this fungus. This work aimed to describe the chemical profile of T. lucida essential oil and to evaluate the in vitro biological effect against B. cinerea. It is expected that the composition of the essential oil is specific and that this oil has a biological effect against the aforementioned phytopathogenic fungus.
In October 2021, samples of Tagetes lucida Cav. in flowering stage (stems, flowers, and leaves) were collected in the municipality of Pilcaya, Cacahuamilpa, Guerrero (18° 40’ 42.6” north latitude, 99° 32’ 31.3” west longitude) at 1 479 m altitude and in a temperate climate with rainfall in summer (Cw1) (Köppen, 1948). The flowering stems were cut 10 cm above the ground to avoid the loss of plants in their habitat since this is perennial and sprouts again. Specimens of these samples were deposited in the Jorge Espinosa Salas JES Herbarium-Hortorio of the Department of Agricultural High School of the Chapingo Autonomous University, State of Mexico (record 35872).
Two liters of drinking water were added to an Italian-type glass distiller, with a capacity of 6 kg; then, 2 kg of fresh plants previously crushed with pruning shears was placed in the balloon flask; essential oil was extracted by hydrodistillation for 45 min (Rodríguez et al., 2012). The essential oil was preserved in amber glass bottles in refrigeration until use; 1.6 ml of essential oil per kilogram of dry weight of plant tissue was obtained.
The essential oil samples were analyzed with the solid-phase microextraction technique (Zhao et al., 2022); to do this, 5 μl of essential oil was added to an amber bottle and a solid-phase microextraction fiber (PALsystem Ingenious Simple Handling) was placed for 1 min; after that, the sample was injected into a gas chromatograph coupled to a mass spectrometer (GC-MS Agilent Technologies 7890 A GC System); two replications were performed and a VF-5ms GC column 30 × 0.25 (0.25) was used.
The temperature of the column oven started at 60 °C, then at 120 °C for 15 min, and a final temperature of 230 °C. The temperature increase was 15 °C min-1 and helium were used as a carrier gas at a constant flow of 0.5 ml min-1. The compounds were identified by comparing the retention time and the mass spectrum with the NIST spectral library and corroborated with Kovats and R match indices greater than 800. N-alkanes were used as references in the calculation of the Kovats indices.
The evaluation was made in potato dextrose agar culture medium (PDA 39 g L-1) with the poisoned agar method (Dikshit and Husain, 1984); an emulsion was prepared with 100 ml of double-distilled water, 100 μl of Tween 20, and essential oil of T. lucida to obtain four concentrations (0.1, 0.5, 1, and 2% v/v). Separately, six concentrations were prepared with Tween 20 (0.1, 0.3, 0.5, 0.8, 1, and 2% v/v), and a commercial fungicide was used: (1 g L-1): Cabrio C (Boscalid 25.2% + Pyraclostrobin 12.8%).
Sterilization was carried out in an autoclave at 120 °C for 20 minutes. The PDA medium was then poured into sterile 90 mm glass Petri dishes. After 24 h, B. cinerea, obtained from the Genetic Resistance Laboratory of the Universidad Autónoma Chapingo (UACH), for its acronym in Spanish, was inoculated. The strain of B. cinerea used has molecular identification with NL4 and ITS5HP indicators (Toju et al.9l, 2012) and GenBank registration PP401673.1.
The experiment was established with a completely randomized design (CRD) with 12 treatments: four concentrations of essential oil, six concentrations of Tween 20, 1 g L-1 of Cabrio C fungicide (Boscalid 25.2% + Pyraclostrobin 12.8%) and one control, each treatment with five replications. A digital vernier was used to measure the radial growth of the fungus every 24 h for five days. Growth rate (GR) (Sinclair and Cantero, 1989) and mycelial growth inhibition (%I) (Kagezi et al., 2015) were evaluated.
A stereo microscope was utilized to observe if there was sporulation from the fifth to the eighth day after the fungus was seeded. A nominal scale was employed. Data were analyzed with Tukey mean tests (p≤ 0.05) through the SAS academic software (SAS Institute Inc, 2023). The results of the essential oil concentrations evaluated in vitro were used to determine the Probit concentrations (LC50 and LC95) in the SAS academic software (Finney, 1971; Castillo, 2007; SAS Institute Inc, 2023).
Thirty-one compounds were identified in the essential oil, with four of them being the major ones: (1S)-(-)-β-pinene (36.4%), 1, 3, 5, 7-cyclooctatetraene (12.7%), eucalyptol (10.6%), and o-cymene (6.1%) (Table 1), of all the compounds, sesquiterpenes represented 40%, monoterpenes 30%, other terpenes 3%, and the rest corresponded to less abundant alcohols. Compounds such as estragole, anethole, methyl eugenol (Bicchi et al., 1997), β-ocimene, β-cubebene, β-myrcene, germacrene, caryophyllene, nerolidol (Regalado et al., 2011) and geranyl acetate (Zárate-Escobedo et al., 2018) have been reported as major compounds in T. lucida, which means that the secondary metabolites that were the majority in the Pilcaya population (Table 1), other than those reported previously in other studies (Table 2), expand the knowledge of the phytochemistry of this species.
When comparing the compounds found in the study population (Table 1), called Pilcaya (1 479 masl), with those found by Zarate-Escobedo et al. (2018) in the locality called El Mogote-Pilcaya (1 493 masl), both points nearby, the main compounds in the essential oil of both populations do not coincide (Table 2). The compound (-)-β-pinene, which had 36.4% abundance in Pilcaya (Table 1), had an abundance of 1.1% in El Mogote-Pilcaya (Table 2) (Zarate-Escobedo et al., 2018).
The Pilcaya site is warmer, possibly by 2 °C, and at a lower altitude (1 479 m) compared to the El Mogote-Pilcaya site. In other species, temperature, water regime and other factors have been recorded as influencing the synthesis of secondary metabolites (Karalija et al., 2022; Valkovszki et al., 2023). The result is valuable for selecting areas for collection and possible cultivation due to the importance that changes in temperature and altitude can have on the type and quantity of chemical compounds.
Regarding the biocidal effect of the essential oil, it was found that, with 1 and 2%, the mycelial growth of B. cinerea was inhibited, with statistical differences compared to the concentration of 0.1% (Table 3), and there was no sporulation of the fungus. Therefore, the concentration of 1% is adequate to verify whether the effect observed at the in vitro level could also be reproduced at the in vivo level with due care not to entail phytotoxicity effects.
[i] Means with equal letters are not statistically different (Tukey, 0.05), CV= coefficient of variation; LSD= least significant difference; *= significance level (p≤ 0.05); TL2= essential oil 2%; TL1= essential oil 1%; TL0.5= essential oil 0.5%; TL0.1= essential oil 0.1%; CF= commercial fungicide Cabrio C.
T. lucida essential oil also inhibits Penicillium notatum, Fusarium moniliforme, Fusarium sporotrichum, Trichophyton mentagrophytes (Céspedes et al., 2006), Sclerotium rolfsii and Monilinia fructicola (Barajas et al., 2011), Aspergillus niger, Fusarium oxysporum, Penicillium janthinellum and Rhizoctonia solani (López et al., 2018). This work presents results against B. cinerea for the first time are (Table 3). The biological effect of 1% T. lucida oil is highlighted since, statistically, it equals the commercial fungicide and this opens up technical-economic possibilities to analyze a possible use of the aforementioned natural resource.
The inhibitory effect caused by the essential oil against fungi is because they cause damage to the cytoplasmic membrane and interrupt several layers of polysaccharides, fatty acids, and phospholipids (Helal et al., 2006; Rammanee and Hongpattarakere, 2011). They also damage hyphae, vacuolation, protoplast leakage or mitochondrial destruction (Rasooli et al., 2006). Soylu et al. (2010) reveal morphological alterations in the hyphae of B. cinerea caused by the application of essential oils of Origanum syriacum, Lavandula stoechas, and Rosmarinus officinalis.
Treatment with Tween 20 (2%) showed inhibition of 24.02% (Figure 1) with a mycelium growth rate of 6.51 mm d-1, whereas with the lowest concentration (0.1%), the inhibition was 5.15% and the growth rate increased to 8.03 mm d-1 (Table 3); the concentrations of 0.1, 0.5, 0.8, and 1% of the surfactant that were tested were not statistically different from the control.
Apparently, the effect of Tween is antifungal-dependent and could be related to the solubility of the antifungal in the medium used; therefore, it is important to standardize the concentration of surfactant for use in the preparation of the inoculum or when making the emulsion in order to ensure reliable results (Gómez-López et al., 2005), since it has been observed that Tween 20 (0.1%) inhibits the germination of Beauveria bassiana conidia by 20% (Mwamburi et al., 2015). In the present experiment, the use of Tween 20 at 0.1% had virtually no inhibitory effect. However, higher concentrations (>0.1%) did inhibit B. cinerea.
In treatments with essential oil and commercial fungicide, there was no sporulation of B. cinerea (Figure 1), whereas in the control and treatment with Tween 20, there was sporulation until the eighth day, which reinforces the biological activity of the T. lucida oil that was evaluated.
The in vitro application of essential oils of Thymus vulgaris, Origanum vulgare, Origanum dictamnus, and Origanum majorana also reduced the production and germination of conidia in Penicillium digitatum (Daferera et al., 2000). The antisporulating effect in Aspergillus fumigatus was related to respiration-inhibiting activity due to the effect of essential oils (Inouye et al., 1998).
The Probit concentrations of the essential oil of T. lucida from Pilcaya were 0.06% (v/v) for LC50 and 1.69% (v/v) for LC95 (Table 4), references that allow us to suggest that T. lucida oil is a candidate plant substance for the biocontrol of B. cinerea. In perspective, it is contemplated to evaluate in vivo the best treatment considering the reference of the Probit analysis and to verify the biological effect of each major compound.
| Essential oil (v/v) | Lethal concentrations | Confidence limits (95%) |
|---|---|---|
| T. lucida | LC50 0.06 | 0.02704-0.09868 |
| LC95 1.69 | 1.07514-3.5546 |
The natural populations of T. lucida in Pilcaya, Cacahuamilpa, Guerrero are abundant and constitute a promising natural resource for their sustainable use at the level of the communities that own these lands, especially if the exploration of biological effects is extended to insect pests, various phytopathogenic fungi, mites, bacteria, and other organisms of importance in human and veterinary medicine, it will yield favorable results.
Of course, it is advisable to assess the financial viability of the oil distillation process in order to have a real picture of the potential for exploiting the plant genetic resource in question. It must be considered that the yield of 1.6 ml is obtained from 1 kg of dry tissue, so to obtain 1 L of oil, 625 kg of dry tissue would be used, which would be approximately equivalent to a volume of 5 t of fresh plant, a scenario that leads us to reflect on possible agroecological management of native populations or take them to conventional cultivation.
T. lucida essential oil contains thirty-one chemical compounds. The major compounds are terpenes and their abundance is associated with the warm temperate climate from which the plant material comes. The essential oil evaluated has an in vitro fungicidal effect against B. cinerea and was validated with the Probit evaluation. Tween 20 partially inhibits growth, so the amount of surfactant to dissolve the oil must be adjusted.
Bicchi, C.; Fresia, M.; Rubiolo, P.; Monti, D.; Franz, C. and Goehler, I. 1997. Constituents of Tagetes lucida Cav. ssp. lucida essential oil. Flavour and Fragrance Journal. 12(1):47-52. https://onlinelibrary.wiley.com/doi/abs/10.1002/%28SICI%291099-1026%28199701%2912%3A1%3C47%3A%3AAID-FFJ610%3E3.0.CO%3B2-7.
Gómez-López, A.; Aberkane, A.; Petrikkou, E.; Mellado, E.; Rodríguez-Tudela, J. L. and Cuenca-Estrella, M. 2005. Analysis of the influence of concentration, inoculum size, assay medium, and reading time on susceptibility testing of Aspergillus spp. Journal of Clinical Microbiology. 43(3):1251-1255. 10.1128/jcm.43.3.1251-1255.2005.
Gutiérrez, G. Y.; Scull, L. R.; García, S. G. y Montes, A. A. 2018. Evaluación farmacognóstica, fitoquímica y biológica de un extracto hidroalcohólico de Tagetes lucida Cavanilles. Revista Cubana de Plantas Medicinales. 23(2). https://revplantasmedicinales.sld.cu/index.php/pla/article/view/669/308.
Kagezi, G. H.; Kucel, P.; Olal, S.; Pinard, F.; Seruyange, J.; Musoli, P. and Kangire, A. 2015. In vitro inhibitory effect of selected fungicides on mycelial growth of ambrosia fungus associated with the black coffee twig borer, Xylosandrus compactus Eichhoff (Coleoptera: curculionidae) in Uganda. African Journal of Agricultural Research. 10(23):2322-2328. 10.5897/ajar12.1705. https://academicjournals.org/journal/AJAR/article-full-text/D7529FA53326.
Karalija, E.; Dahija, S.; Tarkowski, P. and Ćavar-Zeljkovic, S. 2022. Influence of climate-related environmental stresses on economically important essential oils of mediterranean Salvia sp. Frontiers in Plant Science. 13:864807. Doi: 10.3389/fpls.2022.864807. https://www.frontiersin.org/journals/plant-science/articles/10.3389/fpls.2022.864807/full.
Köppen, W. 1948. Climatología: con un estudio de los climas de la tierra. Fondo de Cultura Económica (FCE). México, DF. 479 p. https://books.google.com.mx/books/about/Climatolog%C3%ADa.html?id=kA-IGwAACAAJ&redir-esc=y.
López, L. E.; Peña M. G. O.; Colinas L. M. T.; Diaz, C. F. y Serrato, C. M. A. 2018. Fungistasis del aceite esencial extraído de una población de Tagetes lucida de Hidalgo, México. Revista Mexicana de Ciencias Agrícolas. 9(2):329-341. 10.29312/remexca.v9i2.1075. https://www.scielo.org.mx/scielo.php?script=sci-arttext&pid=S2007-09342018000200329.
Mwamburi, L. A.; Laing, M. D. and Miller, R. M. 2015. Effect of surfactants and temperature on germination and vegetative growth of Beauveria bassiana. Brazilian Journal of Microbiology. 46(1):67-74. 10.1590/s1517-838246120131077. https://pmc.ncbi.nlm.nih.gov/articles/PMC4512050/.
Omer, E. A.; Hendawy, S. F.; El-Deen, A. M. N.; Zaki, F. N.; Abd-Elgawad, M. M.; Kandeel, A. M. and Ismail, R.F. 2015. Some biological activities of Tagetes lucida plant cultivated in Egypt. Advances in Environmental Biology. 9(2):82-88. https://www.researchgate.net/publication/309111820-Some-biological-activities-of-Tagetes-lucida-plant-cultivated-in-Egypt.
Rammanee, K. and Hongpattarakere, T. 2011. Effects of tropical citrus essential oils on growth, aflatoxin production, and ultrastructure alterations of Aspergillus flavus and Aspergillus parasiticus. Food and Bioprocess Technology. 4:1050-1059. 10.1007/s11947-010-0507-1. https://link.springer.com/article/10.1007/s11947-010-0507-1#citeas.
Rasooli, I.; Rezaei, M. B. and Allameh, A. 2006. Growth inhibition and morphological alterations of Aspergillus niger by essential oils from Thymus eriocalyx and Thymus x-porlock. Food Control. 17(5):359-364. 10.1016/j.foodcont.2004.12.002. https://www.sciencedirect.com/science/article/abs/pii/S0956713505000162.
Regalado, E. L.; Fernández, M. D.; Pino, J. A.; Mendiola, J. and Echemendia, O. A. 2011. Chemical composition and biological properties of the leaf essential oil of Tagetes lucida Cav from Cuba . Journal of Essential Oil Research. 23(5):63-67. 10.1080/10412905.2011.9700485. https://www.tandfonline.com/doi/abs/10.1080/10412905.2011.9700485.
SAS Institute Inc. 2023. SAS® OnDemand for Academics. https://www.sas.com/es-mx/software/on-demand-for-academics.html.
Sinclair, C. G. and Cantero, D. 1989. Fermentation modelling. In: fermentation a practical approach. McNeil, B. L. and Harvey, M. (Eds.). IRL Press, New York. 65-112 pp. https://cienciasagricolas.inifap.gob.mx/index.php/agricolas/article/view/2077/3209.
Soylu, E. M.; Kurt, Ş. and Soylu, S. 2010. In vitro and in vivo antifungal activities of the essential oils of various plants against tomato grey mould disease agent Botrytis cinerea. International Journal of Food Microbiology. 143(3):183-189. 10.1016/j.ijfoodmicro.2010.08.015. https://www.sciencedirect.com/science/article/abs/pii/S0168160510004757.
Tančinová, D.; Mašková, Z.; Mendelová, A.; Foltinová, D.; Barboráková, Z. and Medo, J. 2022. Antifungal activities of essential oils in vapor phase against Botrytis cinerea and their potential to control postharvest strawberry gray mold. Foods. 11(19):2945. Doi.org/10.3390/foods11192945. https://www.mdpi.com/2304-8158/11/19/2945.
Torres-Martínez, R.; Moreno-León, A.; García-Rodríguez, Y. M.; Hernández-Delgado, T.; Delgado-Lamas, G. and Espinosa-García, F. J. 2022. Tagetes lucida Cav. essential oil and the mixture of its main compounds are antibacterial and modulate antibiotic resistance in multi-resistant pathogenic bacteria. Letters in Applied Microbiology. 75(2):210-223. 10.1111/lam.1372. https://pubmed.ncbi.nlm.nih.gov/35419861/.
Toju, H.; Tanabe, A. S.; Yamamoto, S. and Sato, H. 2012. High-Coverage ITS primers for the DNA-Based identification of Ascomycetes and Basidiomycetes in environmental samples. Plos One. 7(7):1-11. 10.1371/journal.pone.0040863. https://journals.plos.org/plosone/article?id=10.1371/journal.pone.0040863.
Turner, B. L. 1996. The comps of Mexico: A systematic account of the family Asteraceae, vol. 6. Tageteae and Anthemideae. Phytologia Memoirs. Texensis Publishing. Gruver, Texas, USA. 93 p. https://books.google.com.mx/books/about/The-Comps-of-Mexico-Tageteae-and-Anthemi.html?id=6gZHAAAAYAAJ&redir-esc=y.
Valkovszki, N. J.; Szalóki, T.; Székely, Á.; Kun, Á.; Kolozsvári, I.; Zima, I. S.; Tavaszi-Sárosi, S. and Jancsó, M. 2023. Influence of soil types on the morphology, yield, and essential oil composition of common sage (Salvia officinalis L.). Horticulturae. 9(9):1037. 10.3390/horticulturae9091037. https://www.mdpi.com/2311-7524/9/9/1037.
Zarate-Escobedo, J.; Castañeda-González, E. L.; Cuevas-Sánchez, J. A.; Carrillo-Fonseca, C. L.; Ortiz-Torres, C.; Ibarra-Estrada, E. y Serrato-Cruz, M. A. 2018. Aceite esencial de algunas poblaciones de Tagetes lucida Cav. de las regiones norte y sur del Estado de México. Revista Fitotecnia Mexicana. 41(2):199-209. 10.35196/rfm.2018.2.199-209. https://www.scielo.org.mx/scielo.php?script=sci-arttext&pid=S0187-73802018000200199.
Zhao, J.; Quinto, M.; Zakia, F. and Li, D. 2023. Microextraction of essential oils: a review. Journal of Chromatography A. 1708:464357. 10.1016/j.chroma.2023.464357. https://www.sciencedirect.com/science/article/abs/pii/S0021967323005824.
