Beaucarnea hookeri is a species endemic to Mexico and is listed as threatened in NOM-059-SEMARNAT-2010. In order to micropropagate this species, an experiment was established at the Montecillo Campus, College of Postgraduates in 2022, where the response of the shoots during in vitro multiplication with different concentrations of benzylaminopurine (BAP) and their capacity for ex-vitro rooting during acclimatization were evaluated. An experiment was established with three subsequent subcultures (SC3, SC4, SC4-1); in SC3, shoots generated with 0.5 mg L-1 BAP (SC2) were used; in SC4, healthy shoots generated from SC3; and SC4-1 with shoots from SC3 but with initial hyperhydration (IHH). In SC3, 0.5, 1, 1.5, 2, and 2.5 mg L-1 BAP were evaluated. In SC4, 0 and 0.5 mg L-1 BAP and in SC4-1, concentrations of 0, 0.5, and 1 mg L-1 BAP. During acclimatization, four treatments of Radix® 10 000 (0, 1 000, 2 000, and 4 000 mg kg-1) were evaluated, and shoots from SC2 were used. During multiplication, the number of shoots (NS) was recorded, and SC3 generated 6.35 shoots with the concentration of 1.5 mg L-1 BAP, with the presence of IHH. On average, 9.7 shoots were obtained in SC4, and 5.3 shoots in SC4-1, both subcultures with 0.5 mg L-1 BAP. In addition, there was a recovery of IHH in SC4-1. In rooting, there were no significant differences between treatments, and the control generated 73.3% of shoots with roots (SSR) 80 days after transplantation. Only the shoots of the control treatment in multiplication presented roots, which allowed complete plants to be obtained in 30 days.

Keyword Group [xml:lang=en]

Title: Keywords:

Keyword: Calibanus hookeri

Keyword: endangered

Keyword: in vitro culture

Keyword: Nolinaceae

Keyword: organogenesis.

Counts

Figure Count [count=2]

Table Count [count=4]

Equation Count [count=0]

Reference Count [count=22]

Page Count [count=0]

Abstract

Beaucarnea hookeri is a species endemic to Mexico and is listed as threatened in NOM-059-SEMARNAT-2010. In order to micropropagate this species, an experiment was established at the Montecillo Campus, College of Postgraduates in 2022, where the response of the shoots during in vitro multiplication with different concentrations of benzylaminopurine (BAP) and their capacity for ex-vitro rooting during acclimatization were evaluated. An experiment was established with three subsequent subcultures (SC3, SC4, SC4-1); in SC3, shoots generated with 0.5 mg L-1 BAP (SC2) were used; in SC4, healthy shoots generated from SC3; and SC4-1 with shoots from SC3 but with initial hyperhydration (IHH). In SC3, 0.5, 1, 1.5, 2, and 2.5 mg L-1 BAP were evaluated. In SC4, 0 and 0.5 mg L-1 BAP and in SC4-1, concentrations of 0, 0.5, and 1 mg L-1 BAP. During acclimatization, four treatments of Radix® 10 000 (0, 1 000, 2 000, and 4 000 mg kg-1) were evaluated, and shoots from SC2 were used. During multiplication, the number of shoots (NS) was recorded, and SC3 generated 6.35 shoots with the concentration of 1.5 mg L-1 BAP, with the presence of IHH. On average, 9.7 shoots were obtained in SC4, and 5.3 shoots in SC4-1, both subcultures with 0.5 mg L-1 BAP. In addition, there was a recovery of IHH in SC4-1. In rooting, there were no significant differences between treatments, and the control generated 73.3% of shoots with roots (SSR) 80 days after transplantation. Only the shoots of the control treatment in multiplication presented roots, which allowed complete plants to be obtained in 30 days.

Keywords:

Calibanus hookeri, endangered, in vitro culture, Nolinaceae, organogenesis.

Introduction

Beaucarnea hookeri, synonymy of Calibanus hookeri, is endemic to Mexico, it is recorded in Tamaulipas, San Luis Potosí, Guanajuato, Querétaro, and Hidalgo (De-Nova et al., 2018; Hernández-Sandoval, 2020), grows on igneous rock outcrops and rarely on limestone rocks. It is a distinctive member of the Nolinaceae family, the morphology that distinguishes it is its almost spherical caudex of 0.4 to 1 m in diameter, fissured bark of grayish brown color, leaves arranged in almost sessile rosettes distributed in the caudex giving a cespitous appearance, the leaves with concave blades, 60 to 95 cm long and denticulate margins.

It has paniculate inflorescences, 20-40 cm long, staminate flowers on pedicels 2.5 mm long, pistillate flowers of 1-1.5 mm in diameter, almost spherical to pyriform fruits of 5-8 mm in diameter, thickened pericarp with three ribs along it, seeds 3-4 mm long and 3 mm wide, brown (Martínez et al., 2014; Hernandez-Sandoval, 2020). Calibanus hookeri was formally included within Beaucarnea derived from the study carried out by Rojas-Piña et al. (2014). Hernández-Sandoval (2019) noted that it is one of the genera that were registered as a synonym of Beaucarnea in the Nolinaceae family. In its normative annex III, the DOF (2019) establishes that the species Beaucarnea hookeri (Lem.) Baker is what is commonly known as ‘inaja’ and ‘sacamecate’ (Hernández-Sandoval, 2020).

The recognized synonyms are Calibanus caespitosus, Calibanus hookeri, Dasylirion caespitosum, Dasylirion hartwegianum, Dasylirion hookeri (DOF, 2019). According to NOM-059-SEMARNAT-2010, it is a species in the ‘threatened’ risk category (SEMARNAT, 2010). In this regard, Hernández-Sandoval (2020) reported that Calibanus hookeri is a species found in very localized places and in populations with few individuals, so it is considered threatened and endangered.

For the conservation of this species, recently Núñez et al. (2021) developed an in vitro establishment protocol in MS medium supplemented with cytokinins at high concentrations (2.5, 5, and 7 mg L-1), such as benzylaminopurine (BA), kinetin (K), isopentyl adenine (2ip) and thidiazuron (TDZ), where they determined that the most efficient treatment was with 5 mg L-1 BA, this concentration induced 26 shoots per seedling, although they also mention that it presents susceptibility to hyperhydration.

In studies conducted in the multiplication stage, Gil et al. (2019) reported that in Cattleya trianae, treatments with cytokinins (6-BAP) increased the response in shoots and decreased root formation. Waly et al. (2018) evaluated the effect of the type of medium and the concentration of BAP in the multiplication stage of Beaucarnea recurvata and concluded that for the production of large quantities of plants, the B5 medium supplemented with 0.4 mg L-1 BAP should be used for four weeks. The present study aimed to determine the best treatments with low concentrations of BAP for in vitro multiplication, as well as to evaluate the ex-vitro rooting during the acclimatization of the plants generated from their culture.

Materials and methods

Seeds

They were collected in October 2019 in the Botanical Garden of the Faculty of Higher Studies of Iztacala, UNAM, Mexico, and donated by MS Marcial Pineda, the person in charge of the aforementioned garden, who made the identification of the plant. The seeds were stored for 14 months in a dry place without any treatment within the facilities of the College of Postgraduates, Montecillo, State of Mexico.

Seed disinfestation

It consisted of qualitative selection after removing the testa (based on the color of the seed), greenish and grayish seeds were removed to avoid the presence of fungi and mechanical damage. Once 150 seeds were obtained, they were placed in a beaker containing a solution of 10 g L-1 of Roma® biodegradable detergent and tap water, the beaker was placed for 30 min under the fall of the tap water, and at the end of the time, they were rinsed three times. Subsequently, 70% v/v alcohol was added for 1 min, and it was rinsed with tap water (three consecutive times), then a 30% v/v sodium hypochlorite solution with two drops of tween 20® per 100 ml of solution was used for 30 minutes.

Before completing the 30 min, it was taken to the previously sanitized laminar flow hood, where the chlorine solution was removed, and the seeds were rinsed five times with deionized and sterilized water consecutively; finally, a solution of sulfuric acid 4N was used and added to the seeds for a period of 5 min, at the end of the time, five rinses were carried out consecutively with deionized and sterilized water, then the water was drained from the beaker, and the seeds were ready to be sown in the test tubes.

Sowing of seeds and culture medium

The seeding was done in test tubes with 20 ml of MS base medium (Murashige and Skoog, 1962) supplemented with 2 mg L-1 glycine, 100 mg L-1 myo-inositol, 0.4 mg L-1 thiamine-HCl, 0.5 mg L-1 nicotinic acid, 0.5 mg L-1 pyridoxine HCl, 30 g L-1 sucrose and 8 g L-1 Merk( agar. The pH of the culture medium was adjusted to 5.7 with NaOH 0.1N or HCl 0.1N, and it was sterilized in an autoclave at 1.5 kg cm-2 for 15 min.

The MS medium was used for all subcultures, what changed was the amount of BAP according to the treatments. One seed was sown per test tube of 150 x 22 mm, in a laminar flow hood previously disinfected, and 120 seeds were established for germination. The seeds were exposed to 0, 2.5, and 5 mg L-1 BAP for 80 days, the plants with the highest number of shoots showed hyperhydration, so the mother plants were subcultured with the same characteristics described for the medium, and only the concentrations were changed from 2.5 to 0.5 and 5 to 1 mg L-1, respectively. The shoots generated 30 days after the second subculture were the initial material for the experiments.

Multiplication stage (SC3)

To obtain the plant material for the following subcultures, the shoots were extracted from the tubes and separated in Petri dishes. The individualized shoots were established in a fresh culture medium supplemented with different concentrations of BAP, according to the treatments assigned in the subculture (SC3); that is, the shoots generated in SC2 that were during 30 days of culture with 0.5 mg L-1 BAP after the separation of the mother shoot (Figure 1B) were established in different concentrations of BAP (0, 0.5, 1, 1.5, 2 and 2.5 mg L-1) with 21 repetitions.

Figure 1

Figure 1. A) separation of shoots to establish SC3; B) repetition 10 from left to right (1, 0.5, 2, 2.5, and 1.5 mg L-1 BAP), SC3; C) repetition 18 of the treatments from left to right (0, 2.5, 0.5, 1.5, 2, and 1 mg L-1 BAP) SC4; D) shoots with IHH, generated in SC3; and E) SC4-1 treatments R6 treatments from left to right (1, 0, and 0.5 mg L-1 BAP) SC4-1.


Subculture (SC4)

Healthy shoots generated at concentrations of 0.5, 1, 1.5, 2, and 2.5 mg L-1 BAP, from SC3, were established in 0.5 mg L-1 BAP and a control without regulators, 22 repetitions per treatment were used.

Subculture (SC4-1)

Shoots with initial hyperhydration (Figure 1D) were established at random in 0, 0.5, and 1 mg L-1 BAP with 22 repetitions. The variables recorded for the experiments were the following: in rooting, number of roots (NR), root length (RL) in cm, percentage of survival of shoots with root (PSSR); and in the subcultures of multiplication, number of shoots (NS), leaf length (LL) in cm, stem base width (SBW) in cm, percentage of shoots with root (PSR) and percentage of propagule shoots hyperhydrated (PSHH).

Ex-vitro rooting

The shoots generated in the second subculture (SC2) after 30 days were used, they were separated from the shoots they generated, and these were returned to their test tube, and after 58 days, 60 shoots were established in a completely randomized experiment with 15 repetitions at 0, 1 000, 2 000 and 4 000 mg kg-1 of Radix 10 000®, in cells. The mixture was prepared with Radix® 10 000 and talc without aroma. Cells of 140 ml in volume supported by their bases were used, both were washed with a solution of Roma® biodegradable detergent and rinsed with tap water, and disinfected with a 30% v/v NaOCl solution for 20 min.

The substrate mixture that was used was based on Promix® Peat moss and perlite (1:1 v/v), sterilization was performed in an autoclave at a pressure of 1.7 kg cm-2, 30 min (twice). The shoots were extracted, and the base of the stem was sprinkled with a solution of Timsem® 1 g L-1. The agar was removed from the base of the stem with deionized and sterilized water, excess water was removed from the base of the stem, then it was impregnated with the Radix® mixture according to the assigned treatment, after being transplanted, each shoot was irrigated with 20 ml of sterilized deionized water. An 8 x 26 bag was placed on each cell to create a microclimate, holding it with a band to start the rooting process. The cells were transferred to the incubation room, where they were placed in a photoperiod of 16 h light and 8 h dark, with cold-white light lamps, with an intensity of 80 μmol m-2 s-1. At day 40, the bag was removed from the cells, and they were kept in the incubation room until 80 days, during which time the evaluation was performed.

Statistical analysis

A completely randomized design was used in all four experiments; data analysis was performed using the one-factor Anova technique, followed by Tukey’s multiple comparison test, the honestly significant difference (HSD). In the case of the variables of subculture, PSR and PHH, and that of rooting, PSSR, they were analyzed by logistic regression because they are binomial variables, and the comparison of means was by emmeans Tukey, all analyses were performed in the statistical program RStudio.

Results and discussion

Multiplication in the subculture of shoots (SC3)

Number of shoots (NS)

The formation of adventitious shoots at the base of the stem was significant (p≤ 0.05) among the treatments, the highest values (6.35 and 5.71 shoots per propagule) were recorded with 1.5 and 2.5 mg L-1 BAP, respectively (Table 1 and Figure 1B). The results of this research are superior to those by (Osorio-Rosales, 2005), when they used seedlings without roots and trimmed leaves as explant, they generated 5.4 shoots per seedling in B. gracilis at a concentration of 5 mg L-1 BAP, and with 1 mg L-1 BAP, they generated 1.9 shoots per explant in B. recurvata, but they are lower when they used the explant of longitudinal sections in B. gracilis and B. recurvata, with 5 mg L-1 BAP they induced 8.2 and 11.1 shoots per explant.

Table 1

Table 1. Response of B. hookeri shoots generated in 0.5 mg L -1 BAP, exposed to BAP concentrations of SC3 to 30 after the beginning.

Treatments LL (cm) NS NR RL (cm) PSR PHH
BAP (mg L-1)
0 7.78 a 0.14 b 0.38 a 1.34 a 33 a 10 a
0.5 3.29 b 4.33 a 0 b 0 b 0 a 19 a
1 2.3 b 5.52 a 0 b 0 b 0 a 29 a
1.5 2.09 b 6.35 a 0 b 0 b 0 a 45 a
2 2.56 b 5.66 a 0 b 0 b 0 a 52 a
2.5 1.94 b 5.71 a 0 b 0 b 0 a 67 b
* 2.2x10-16 9.7x10-08 4.9x10-07 2.1x10-07 5.2x10-05 0.0004

[i] LL= longest leaf length in cm; NS= number of shoots; NR= number of main adventitious roots; RL= Longest adventitious root length; PSR= percentage of shoots with roots; PHH= percentage of hyperhydration of propagule shoots; *= p-value. Means with different letters in the same column are statistically different, according to the Tukey test (p≤ 0.05).

They also coincide with what was reported by Reyes-Silva et al. (2013), by using basal explants of 10 to 15 mm, without leaves or roots in MS medium supplemented with BAP at concentrations of 3 to 4 mg L-1 in 10 species of the genera Beaucarnea, Dasylirion, and Nolina, they generated 3.9 to 10.3 shoots per explant. They also coincide with Vadillo-Pro et al. (2016), with explants of longitudinal sections of B. purpusii and a concentration of 3 mg L-1 BA, they induced 6.74 shoots per explant.

Leaf length (LL) in cm

The longest leaf lengths (7.78 and 3.29 cm) were obtained in 0 and 0.5 mg L-1 BAP (Table 1), which were significant (p≤ 0.05). The results coincide with Osorio-Rosales (2005), who reported that the development of the first shoot inhibited or limited the development of subsequent shoots, this explains the heterogeneity observed for the height of shoots from 0.3 to 10 cm in B. recurvata and B. gracilis.

Number of roots (NR), root length (RL) in cm, and percentage of shoots with root (PSR)

The NR, RL, and PSR were significant (p≤ 0.05). The NR (0.38 roots) were only present in shoots of the control treatment (0 mg L-1 BAP), no roots formed in the other treatments. The root length was 1.34 cm in the control (Table 1). The above results coincide with Gil et al. (2019), who found that without the application of regulators, higher root percentages were obtained in Cattleya trianae.

The results obtained by Núñez et al. (2021) in C. hookeri were higher, (100%) of rooting in MS medium without regulators. Regarding the percentage of shoots with roots, 33% was obtained in the control, and the other treatments with BAP did not form roots (Table 1). These results differ from Guillén et al. (2015), who registered a higher percentage of in-vitro rooting (92.6%) obtained in B. inermis with an MS medium without phytohormones. Also, the results they achieved in the genus Beaucarnea in MS medium with 2 g L-1 of activated carbon were higher, 63 and 75% rooting (Reyes-Silva et al., 2013). The result obtained is a lower percentage of rooting in the control compared to B. gracilis and B. recurvata, where the rooting of more than 60 and 80% of the shoots cultured in MS medium without the application of phytohormones was observed.

Percentage of hyperhydration of propagule shoots

The treatment with the highest hyperhydration was the treatment of 2.5 mg L-1 BAP with 67% hyperhydration (Table 1). Similar results were reported by Vargas-Castillo (2010), who found 28.66 to 41% hyperhydration in Geophila macropoda at concentrations of 3 and 4 mg L-1. Vadillo-Pro et al. (2016) recorded that explant exposure to 0.1 to 0.5 mg L-1 TDZ showed 4.38 and 7.31 hyperhydrated shoots per explant, respectively, as well as 5 mg L-1 BA showed 3.62 hyperhydrated shoots per explant.

Healthy shoot subculture (SC4)

Number of shoots (NS)

The formation of adventitious shoots at the base of the stem was significant (p≤ 0.05) among the treatments, the highest NS was generated with the concentration 0.5 mg L-1 BAP, OS (9.7 shoots per propagule), the other two best concentrations that produced the highest number of shoots (7.37 and 7.21 shoots per propagule) were 1 and 1.5 mg L-1 BAP of shoot origin (Table 2). The numbers of shoots reported by (Waly et al., 2018) in B. recurvata in the optimal concentration of 0.4 mg L-1 BAP in B5 medium for the multiplication stage are lower. Also, Gil et al. (2019) in Cattleya trianae, where low doses of BAP (0.05 mg L-1) generated the highest percentage of shoots, treatments with BAP 0.5 and 2 mg L-1 increased the shoot response and decreased root formation.

Table 2

Table 2. Response of healthy shoots of C. hookeri with SC3 origin, subcultured 30 days at concentrations of 0 and 0.5 mg L -1 BAP, SC4.

Treatments LL (cm) NS NR30 RL30 (cm) PSR PHH
BAP mg L-1 OS
0 0.5 10.22 a 0.04 c 1.04 a 3.25a 68 a 0 a
0.5 0.5 4.33 b 9.7 a 0 b 0 b 0 a 14 a
0.5 1 3.54 bc 7.37 ab 0 b 0 b 0 a 18 a
0.5 1.5 3.03 bc 7.21 ab 0 b 0 b 0 a 5 a
0.5 2 2.6 c 5.81 b 0 b 0 b 0 a 23 a
0.5 2.5 2.4 c 6.09 b 0 b 0 b 0 a 5 a
* 2.2x10-16 5.06x10-12 2.2x10-16 2.2x10-16 7.1x10-13 0.051

[i] OS= origin of SC3 shoot 0.5, 1, 1.5, 2, 2.5 mg L-1; LL= longest leaf length; NS= number of shoots; NR= number of main adventitious roots; RL= Longer adventitious root length; PSR: percentage of shoots with root; PHH= percentage of propagule shoots hyperhydrated; *= p-value. Means with different letters in the same column are statistically different, according to the Tukey test (p≤ 0.05).

Leaf length (LL) in cm

The variable LL was significant (p≤ 0.05), where the best treatment for the longest LL (10.22 cm) was the control, and the second-best treatment was 0.5 mg L-1 (4.33 cm) (Table 3). Adelberg and Naylor (2012) reported that, when using a liquid medium, the plants were larger and the negative effect of rooting decreased, without affecting the multiplication rate, so the concentration of 6 μM (1.35 mg L-1) BA in a liquid medium was optimal for the multiplication and rooting of Aloe barbadensis.

Table 3

Table 3. Response in the recovery of shoots with IHH, origin of SC3, 1.5, 2, and 2.5 mg L-1 BAP and generation of shoots at day 30, SC4-1.

Treatment LL (cm) SBW (cm) NS NR RL (cm) PSR HH5 HH30
BAP (mg L-1)
0 6.78 a 0.31 b 0.09 b 0.71 a 1.44 a 43 a 95.2 a 23.8 a
0.5 3.76 b 0.66 a 5.63 a 0 b 0 b 0 a 86.4 a 18.2 a
1 1.89 b 0.74 a 5.4 a 0 b 0 b 0 a 90.9 a 22.7 a
* 6.4x10-6 1.3x10-6 5.9x10-10 3E-04 1E-04 7.5x10-06 0.59 0.89

[i] LL= leaf length in cm; SBW= stem base width in cm; NS= number of shoots; NR= number of adventitious roots; RL= root length; *= p-value. Means with different letters in the same column are statistically different, according to the Tukey test (p≤ 0.05).

Number of roots (NR), root length (RL) in cm, and percentage of shoots with root (PSR)

With respect to NR and RL, they were significant at p≤ 0.05; however, the PSR was not significant at the same level of significance. The NR (1.04 roots) were only present in shoots of the control treatment (0 mg L-1 BAP) since no roots formed in the other treatments. The root length was 3.25 cm in the control (Table 1). The treatment without phytohormones in the MS medium allowed the formation of roots in B. inermis, although to a lesser extent compared to 1 mg L-1 IBA (Guillen et al., 2015).

The percentage of shoots with roots was 68% in the control, and the other treatments with BAP did not form roots (Table 1). For their part, Vadillo-Pro et al. (2016) reported that in shoots subcultured individually in B. purpusii in MS medium and ½ MS, both supplemented with 1 g L-1 of activated carbon, they induced 85 to 95% of shoots.

Percentage of hyperhydration of propagule shoots (PHH)

The percentage of hyperhydration ranged from 5% to 23% (Table 2); nevertheless, this variable was not significant (p≤ 0.05). The results obtained coincide with Vargas-Castillo (2010), who found hyperhydration in percentages less than 20% in the media that were supplemented with 0 to 2 mg L-1 BAP in G. macropoda.

Subculture of shoots with IHH (SC4-1)

The variables LL, SBW, NS, NR, and RL were significant, except for PSR and PHH, at p≤ 0.05. At the concentration of 0.5 and 1 mg L-1 of the origin of the shoot, no significant differences were found (Table 3). The results obtained by Ramírez-Gottfried et al. (2021) were superior when comparing the MS medium with vermicompost in the multiplication stage of Dasylirion cedrosanum. The addition of 1 mg L-1 BAP plus 0.2 mg L-1 IAA in MS medium generated higher average shoots (8.25 shoots/explant). In Aloe barbadensis, the concentration of 6 μM (1.35 mg L-1) BA in a liquid medium was optimal for multiplication and rooting.

Leaf length (LL) in cm

The longest leaf lengths (6.78 cm) were obtained in the control (0 mg L-1 BAP) (Table 3). The importance of larger leaf lengths was proven by Aureoles-Rodríguez et al. (2008), who determined that plant size and culture medium affected plant rooting in Agave inaequidens. Plants 4 cm long with more than two roots had a survival of 100%.

Number of roots (NR), root length (RL) in cm, and percentage of shoots with root (PSR)

The NR, RL, and PSR were significant (p≤ 0.05). The NR (0.71 roots) were only present in shoots of the control treatment (0 mg L-1 BAP) since no roots formed in the other treatments. The root length was 1.44 cm in the control. The results coincide with Zhang et al. (2013), who, in an MS medium free of regulators, obtained shoots of Agave hybrid regenerated by organogenesis.

The percentage of shoots with roots was 43% in the control, and the other treatments with BAP did not form roots (Table 3). In this regard, Reyes-Silva et al. (2013) reported that when evaluating rooting at 45-50 days in shoots generated in multiplication with a base medium at 50% in species Beaucarnea goldmanii, B. recurvata and B. gracilis, the lowest percentages of rooting were obtained (34, 23 and 14% respectively), but not in the genera Dasylirion and Nolina, which reached 75 to 100% rooting. Likewise Vargas-Castillo (2010) determined hyperhydration in percentages less than 20% in the media that were supplemented with 0 to 2 mg L-1 BAP in G. macropoda.

Percentage of shoots hyperhydrated

At day 5 after being established in the subculture medium, the shoots did not show significant differences, the percentages of hyperhydration ranged from 86.4 to 95.2% (Table 4). Initial hyperhydration occurred in younger leaves with light green to light yellow coloration in shoots sown at 1 mg L-1 BAP. In the case of 1.5, 2, and 2.5, in addition to the above symptoms, they showed wider bases than the mother shoot, as well as slight leaf deformation and a smaller number. At 30 days of subculture, hyperhydration was evaluated, the concentrations in the three treatments helped in the recovery of the initial hyperhydration, and there were no significant differences between treatments (Table 3 and Figure 1E). The above results coincide with (Millán-Soto et al., 2019), who reported a reduction of hyperhydration by 10.4% in Asparagus officinalis when reseeding rhizomes in a culture medium without growth regulators.

Ex-vitro rooting

Percentage of survival of rooted shoots (PSSR)

Root formation was observed in all treatments; however, the highest percentage of survival of shoots with roots (73.33%) was obtained in the control (Table 4 and Figure 2). The increased survival of rooted shoots (propagule shoots subjected to rooting after separation from their shoots) can be explained by the ability of some species to regenerate roots. This behavior is similar to what was obtained by Guillen et al. (2015) in shoots of B. inermis.

Table 4

Table 4. Ex-vitro rooting and acclimatization of shoots after their first shoot production in B. hookeri 80 days after transplantation.

Treatments NR RL PSSR
(mg kg-1)
0 2.41 a 11.43 a 73.3 a
1 000 2.12 a 9.87 a 33.3 a
2 000 1.76 a 5.73 a 46.7 a
4 000 1.2 a 4.89 a 40 a
* 0.41 0.1 0.1272

[i] NR= number of primary roots; RL= primary root length; PSSR= percentage of survival of shoots with roots; *= p≤ 0.05. Means with different letters in the same column are statistically different, according to the Tukey test (p≤ 0.05).

Figure 2

Figure 2. Ex-vitro rooting treatments, 80 days after establishment. A) 1 000 mg kg -1 ; B) 2 000 mg kg -1 ; C) 4 000 mg kg -1 ; and D) 0 mg kg -1 .


In Cattleya trianae, treatment without BAP formed roots in 7.35% (Gil et al., 2019). On the other hand, Puente-Garza et al. (2015) established the shoots obtained in multiplication in MS medium without regulators, and at 30 days, they generated roots in Agave salmiana, which allowed their successful acclimatization. Zhang et al. (2013) employed regulator-free MS medium in Agave hybrid shoots, regenerated by organogenesis, these generated an average number of 5.39 roots per shoot with a length of 8.44 cm per root within 30 days.

The low rooting of the shoots that were immersed in a mixture with Radix® could possibly be affected by the amount of talc that was impregnated at the base of the stem, being a physical obstacle between the shoot and substrate. In the subcultures of this research, the shoots in the control treatments that did not have regulators generated 33% in SC3, 68% in SC4, and 43% in SC4-1 in a period of 30 days of subculture, these were only exposed to BAP for 30 days when they were generated from the propagule shoot, while the shoots in ex-vitro rooting were twice as long.

The results are similar to those by Adelberg and Naylor (2012), who reported that exposure of shoots to cytokinins such as BAP inhibited rooting. This may be because a cytokinin remnant inhibited rooting, and plants in agar were more affected than plants in the liquid medium. This remnant reduced rooting from 92% (control) to 68% with 10 μM (2.25 mg L-1) BAP in Aloe barbadensis plants.

Conclusions

The dose of 0.5 mg L-1 BAP allows the highest shoot production in 30 days, with increased leaf length. In addition, this concentration contributes to ex-vitro rooting and decreases the probability of the appearance of hyperhydrated shoots. The control treatment (BAP 0 mg L-1) can be used to root healthy and good-sized shoots in 30 days since, at the same time they grow, they form roots, and in 60 days, there is a complete and acclimatized plant.

Acknowledgements

The author María del Rosario Chávez-Muñoz thanks the National Council of Science and Technology (CONACYT, for its acronym in Spanish) for the scholarship support to the student of the master’s degree in Agricultural Sciences.

Bibliography

1

Adelberg, J. and Naylor, A. J. 2012. Effect of cytokinin on multiplication and rooting of Aloe barbadensis during micropropagation on agar and liquid medium. USA. J. Medicinally Active Plants. 1(1):1-5. Doi: https://doi.org/10.7275/R5251G4V.

J. Adelberg A. J. Naylor 2012Effect of cytokinin on multiplication and rooting of Aloe barbadensis during micropropagation on agar and liquid mediumUSA. J. Medicinally Active Plants1115https://doi.org/10.7275/R5251G4V

2

Aureoles-Rodríguez, F.; Rodríguez-de la O, J. L.; Legaria-Solano, J. P.; Sahagún-Castellanos, J. y Peña-Ortega, M. G. 2008. Propagación in vitro del ‘maguey bruto’ (Agave inaequidens Koch.) una especie amenazada de interés económico. México. Revista Chapingo Serie Horticultura. México. 14(3):263-269. http://www.scielo.org.mx/scielo.php?script=sci-arttext&pid=S1027-152X2008000300006.

F. Aureoles-Rodríguez J. L. Rodríguez-de la O J. P. Legaria-Solano J. Sahagún-Castellanos M. G. Peña-Ortega 2008Propagación in vitro del ‘maguey bruto’ (Agave inaequidens Koch.) una especie amenazada de interés económico. MéxicoRevista Chapingo Serie HorticulturaMéxico143263269http://www.scielo.org.mx/scielo.php?script=sci-arttext&pid=S1027-152X2008000300006

3

De-Nova, J. A.; Castillo-Lara, P.; Gudiño-Cano, A. K. y García-Pérez, J. 2018. Flora endémica del estado de San Luis Potosí y regiones adyacente en México. México. Árido-Ciencia. 3(1):21-41. https://www.researchgate.net/publication/326260668-Flora-endemica-del-estado-de-San-Luis-Potosi-y-Regiones-Adyacentes-en-Mexico.

J. A. De-Nova P. Castillo-Lara A. K. Gudiño-Cano J. García-Pérez 2018Flora endémica del estado de San Luis Potosí y regiones adyacente en MéxicoMéxicoÁrido-Ciencia312141https://www.researchgate.net/publication/326260668-Flora-endemica-del-estado-de-San-Luis-Potosi-y-Regiones-Adyacentes-en-Mexico

4

DOF. 2019. Diario Oficial de la Federación. Modificación del anexo normativo III, lista de especies en riesgo de la Norma Oficial Mexicana NOM-059-SEMARNAT-2010, protección ambiental-Especies nativas de México de la flora y fauna silvestre-Categorías de riesgo y especificaciones para su inclusión, exclusión o cambio-Lista de especies en riesgo, publicada.

DOF 2019Diario Oficial de la Federación. Modificación del anexo normativo III, lista de especies en riesgo de la Norma Oficial Mexicana NOM-059-SEMARNAT-2010, protección ambiental-Especies nativas de México de la flora y fauna silvestre-Categorías de riesgo y especificaciones para su inclusión, exclusión o cambio-Lista de especies en riesgo, publicada

5

Gil, C. A. I.; Ariza, C. C. A; Castillo, T. L. M.; Salgado, D. L. E.; Banda, S. L. y Vanegas, M. L. E. 2019. Inducción de organogénesis in vitro con 6-bencilaminopurina en Cattleya trianae Linden & Rchb.f. Colombia. Rev. UDCA. & Div. Cient. 22(2):1-9. http://doi.org/10.31910/rudca.v22.n2.2019.1275.

C. A. I. Gil C. C. A Ariza T. L. M. Castillo D. L. E. Salgado S. L. Banda M. L. E. Vanegas 2019Inducción de organogénesis in vitro con 6-bencilaminopurina en Cattleya trianae Linden & Rchb.f. ColombiaRev. UDCA. & Div. Cient.22219http://doi.org/10.31910/rudca.v22.n2.2019.1275

6

Guillen, S.; Martínez, P. A.; Martínez, H. y Martínez, A. J. G. 2015. Organogénesis y embriogénesis somática de Beaucarnea inermis (Asparagaceae) una especie amenazada del noreste de México. México. Botanical Science. 93(2):221-230. https://botanicalsciences.com.mx/index.php/botanicalSciences/article/view/129/pdf-126.

S. Guillen P. A. Martínez H. Martínez A. J. G. Martínez 2015Organogénesis y embriogénesis somática de Beaucarnea inermis (Asparagaceae) una especie amenazada del noreste de MéxicoMéxicoBotanical Science932221230https://botanicalsciences.com.mx/index.php/botanicalSciences/article/view/129/pdf-126

7

Hernández-Sandoval, L. 2019. Catálogo nomenclatural de la familia Nolinaceae Nakai en México. Universidad Autónoma de Querétaro. Facultad de Ciencias Naturales. Bases de datos SNIB-CONABIO proyecto KT011. México, Ciudad de México. http://www.conabio.gob.mx/institucion/proyectos/resultados/KT011-Apendice-Listado-Taxonomico.pdf.

L. Hernández-Sandoval 2019Catálogo nomenclatural de la familia Nolinaceae Nakai en MéxicoUniversidad Autónoma de QuerétaroFacultad de Ciencias NaturalesBases de datos SNIB-CONABIO proyecto KT011México, Ciudad de Méxicohttp://www.conabio.gob.mx/institucion/proyectos/resultados/KT011-Apendice-Listado-Taxonomico.pdf

8

Hernández-Sandoval, L. 2020. Flora del Bajío y de regiones adyacentes. Fascículo 213. Familia Nolinaceae. 213:1-42. https://www.researchgate.net/publication/340247 199-nolinaceae-flora-del-bajio-y-de-regiones-adyacentes.

L. Hernández-Sandoval 2020Flora del Bajío y de regiones adyacentesFascículo 213Familia Nolinaceae213142https://www.researchgate.net/publication/340247 199-nolinaceae-flora-del-bajio-y-de-regiones-adyacentes

9

Martínez, M.; Hernández, S. L. and Carrillo, L. 2014. Foliar anatomy of Beaucarnea Lemaire (Nolinaceae ss). Plant Syst Evol. 300(1):2249-2258. Doi: 10.1007/s00606-014-1048-2.

M. Martínez S. L. Hernández L. Carrillo 2014Foliar anatomy of Beaucarnea Lemaire (Nolinaceae ss).Plant Syst Evol.30012249225810.1007/s00606-014-1048-2

10

Millán-Soto, G.; Robert, M. L.; Tiznado-Hernández, M. E.; Gutiérrez, A. y Esqueda, M. 2019. Organogénesis de rizoma de espárrago (Asparagus officinalis L.) por combinación de auxinas y citocininas. México. Agrociencia. 53(4):549-561. https://agrociencia-colpos.mx/index.php/agrociencia/article/view/1827.

G. Millán-Soto M. L. Robert M. E. Tiznado-Hernández A. Gutiérrez M. Esqueda 2019Organogénesis de rizoma de espárrago (Asparagus officinalis L.) por combinación de auxinas y citocininas. MéxicoAgrociencia534549561https://agrociencia-colpos.mx/index.php/agrociencia/article/view/1827

11

Murashige, T. and Skoog, F. 1962. A revised medium for rapid growth and bioassays with tobacco tissue culture. USA. Physiol. Plant. 15(3):473-497. https://doi.org/10.1111/j.1399-3054.1962.tb08052.x.

T. Murashige F. Skoog 1962A revised medium for rapid growth and bioassays with tobacco tissue culture. USAPhysiol. Plant.153473497https://doi.org/10.1111/j.1399-3054.1962.tb08052.x

12

Núñez, C. C.; González, R. H. y Fernández, P. Y. L. 2021. Micropropagación de Calibanus hookeri (lem.) trel. (1911). Una especie amenazada. Colombia. Rev. Colomb. Biotecnol. 23(1):46-54. https://doi.org/10.15446/rev.colomb.biote. v23n1.80873.

C. C. Núñez R. H. González P. Y. L. Fernández 2021Micropropagación de Calibanus hookeri (lem.) trel. (1911). Una especie amenazada. ColombiaRev. Colomb. Biotecnol2314654https://doi.org/10.15446/rev.colomb.biote. v23n1.80873

13

Puente-Garza, C. A.; Gutiérrez-Mora, A. and García-Lara, S. 2015. Micropropagation of Agave salmiana: Means to production of antioxidant and bioactive principles. Australia. Frontier in Plant Science. 6(1026):1-9. https://www.ncbi.nlm.nih.gov/pmc/articles/PMC4655248/.

C. A. Puente-Garza A. Gutiérrez-Mora S. García-Lara 2015Micropropagation of Agave salmiana: Means to production of antioxidant and bioactive principles. AustraliaFrontier in Plant Science6102619https://www.ncbi.nlm.nih.gov/pmc/articles/PMC4655248/

14

Osorio-Rosales, M. L. and Mata-Rosas, M. 2005. Micropropagation of endemic and endangered Mexican species of ponytail palms. USA. Hortscience. 40(5):1481-1484. https://www.researchgate.net/publication/268431289-Micropropagation-of-Endemic-and-E ndangered-Mexican-Species-of-Ponytail-Palms.

M. L. Osorio-Rosales M. Mata-Rosas 2005Micropropagation of endemic and endangered Mexican species of ponytail palms. USAHortscience40514811484

15

Ramírez-Gottfried, R. I.; Puente-Valenzuela, C. O.; Chávez-Simental, J. A.; Espinosa-Palomeque, B.; García-Carrillo, M.; Guillén-Enríquez, R. R. y González-Cervantes, G. 2021. Extracto de vermicompost como medio basal en la etapa de multiplicación y enraizamiento in vitro Dasylirion cedrosanum. Terra Latinoamericana. 39:1-11. http://www.scielo.org.mx/scielo.php?script=sci-arttext&pid=S018757792021000100149.

R. I. Ramírez-Gottfried C. O. Puente-Valenzuela J. A. Chávez-Simental B. Espinosa-Palomeque M. García-Carrillo R. R. Guillén-Enríquez G. González-Cervantes 2021Extracto de vermicompost como medio basal en la etapa de multiplicación y enraizamiento in vitro Dasylirion cedrosanumTerra Latinoamericana39111http://www.scielo.org.mx/scielo.php?script=sci-arttext&pid=S018757792021000100149

16

Rojas-Piña, V.; Olson, M. E.; Alvarado-Cárdenas, L. O. and Eguiarte, L. E. 2014. Molecular phylogenetics and morphology of Beaucarnea (Ruscaceae) as distict from Nolina and submersion of Calibanus into Beuacarnea. USA.Taxon. 63(6):1193-1211. https://www.researchgate.net/publication/269998108-Molecular-phylogenetics-and-morphology-of-Beaucarnea-Ruscaceae-as-distinct-from-Nolina-and-the-submersion-of-Calibanus-into-BeaucarneaI/link/56c7841508ae 5488f0d2d866/download.

V. Rojas-Piña M. E. Olson L. O. Alvarado-Cárdenas L. E. Eguiarte 2014Molecular phylogenetics and morphology of Beaucarnea (Ruscaceae) as distict from Nolina and submersion of Calibanus into Beuacarnea.USA.Taxon63611931211https://www.researchgate.net/publication/269998108-Molecular-phylogenetics-and-morphology-of-Beaucarnea-Ruscaceae-as-distinct-from-Nolina-and-the-submersion-of-Calibanus-into-BeaucarneaI/link/56c7841508ae 5488f0d2d866/download

17

Reyes-Silva, A. I.; Morales-Muñoz, C. F.; Pérez-Reyes, M. E. y Pérez-Molphe, E. 2013. Propagación in vitro de nolináceas mexicanas. México. Investigación y ciencia de la Universidad de Aguascalientes. 21(58):2-20. https://www.redalyc.org/pdf/674/67428815002.pdf.

A. I. Reyes-Silva C. F. Morales-Muñoz M. E. Pérez-Reyes E. Pérez-Molphe 2013Propagación in vitro de nolináceas mexicanas. MéxicoInvestigación y ciencia de la Universidad de Aguascalientes2158220https://www.redalyc.org/pdf/674/67428815002.pdf

18

SEMARNAT. 2010. Secretaría de Medio Ambiente y Recursos Naturales. Norma Oficial Mexicana NOM-059-SEMARNAT-2010, Protección ambiental-especies nativas de México de flora y fauna silvestres-categorías de riesgo y especificaciones para su inclusión, exclusión o cambio-Lista de especies en riesgo. Diario Oficial de la Federación.

SEMARNAT 2010Secretaría de Medio Ambiente y Recursos NaturalesNorma Oficial Mexicana NOM-059-SEMARNAT-2010, Protección ambiental-especies nativas de México de flora y fauna silvestres-categorías de riesgo y especificaciones para su inclusión, exclusión o cambio-Lista de especies en riesgoDiario Oficial de la Federación

19

Vargas-Castillo, M. P. y Abdelnour-Esquivel, A. 2010. Cultivo in vitro de Geophila macropoda (Ruiz & Pav. Dc) a partir de embriones cigóticos. Costa Rica. Agronomia Mesoamericana. 21(1):73-83. https://www.scielo.sa.cr/pdf/am/v21n1/a08v21n1.pdf.

M. P. Vargas-Castillo A. Abdelnour-Esquivel 2010Cultivo in vitro de Geophila macropoda (Ruiz & Pav. Dc) a partir de embriones cigóticos. Costa RicaAgronomia Mesoamericana2117383https://www.scielo.sa.cr/pdf/am/v21n1/a08v21n1.pdf

20

Vadillo-Pro, Ma. C.; Hernández-Sandoval, L. and Malda-Barrera, G. 2016. in vitro regeneration from longitudinal sections of seedling of Beaucarnea purpusi Rose, an endemic and endangered species. USA. HortScience. 51(3):279-284. https://journals.ashs.org/hortsci/view/journals/hortsci/51/3/article-p279.xml.

Ma. C. Vadillo-Pro L. Hernández-Sandoval G. Malda-Barrera 2016in vitro regeneration from longitudinal sections of seedling of Beaucarnea purpusi Rose, an endemic and endangered species. USA.HortScience513279284https://journals.ashs.org/hortsci/view/journals/hortsci/51/3/article-p279.xml

21

Waly, K. A.; Abdel, F. M. and Shoman, A. A. 2018. Effect of media type and BAP concentrations of micropropation during multiplication stage on ponytail palm (Beaucarnea recurvata Lem.). Egypt. Hortscience Journal of Suez Canal University. 7(1):41-45. Doi:16.21608/hjsc.2018.58333.

K. A. Waly F. M. Abdel A. A. Shoman 2018Effect of media type and BAP concentrations of micropropation during multiplication stage on ponytail palm (Beaucarnea recurvata Lem.). EgyptHortscience Journal of Suez Canal University.71414516.21608/hjsc.2018.58333

22

Zhang, Y. M.; Li, X.; Chen, Z.; Li, J. F.; Lu, J. Y. and Zhou, W. Z. 2013. Shoot organogénesis and plant regeneration in agave hybrid, No.11648. Scientia Hortculturae. China. 161:30-34. https://www.sciencedirect.com/science/article/abs/pii/S0304423813003464.

Y. M. Zhang X. Li Z. Chen J. F. Li J. Y. Lu W. Z. Zhou 2013Shoot organogénesis and plant regeneration in agave hybrid, No.11648Scientia Hortculturae. China.1613034https://www.sciencedirect.com/science/article/abs/pii/S0304423813003464
