Revista Mexicana Ciencias Agrícolas volume 10 number 6 August 14 - September 27, 2019
DOI: https://doi.org/10.29312/remexca.v10i6.1767
Article
InfoStat, InfoGen and SAS for mutually orthogonal contrasts in randomized complete block experiments in subdivided plots
Andrés González Huerta§
Delfina de Jesús Pérez López
Martín Rubí Arriaga
Francisco Gutiérrez Rodríguez
J. Ramón Pascual Franco Martínez
Araceli Padilla Lara
Faculty of Agricultural Sciences-Center for Research and Advanced Studies in Plant Breeding-Autonomous University of the State of Mexico. El Cerrillo Piedras Blancas, State of Mexico. AP. 435. Tel. and Fax. 722 2965518, ext. 148 (djperezl@uaemex.mx; m-rubi65@yahoo.com.mx; fgrfca@hotmail.com; jrfrancom@uaemex.mx; padillalaraaraceli@hotmail.com).
§Corresponding author: agonzalezh@uaemex.mx.
Abstract
The series of experiments (SE) in time and space in arrangements of divided plots have been used daily in various disciplines of science and technology, but for subdivided plots (PS) there is little information. With mutually orthogonal contrasts (CMO’s), the variability of means or total treatments in groups is divided into an analysis of variance in experiments of one or more factors. This study presents the programs to analyze data of the pod weight in green registered in fava beans in an SE in complete blocks at random in arrangement of PS to run in the System for Statistical Analysis, InfoStat or InfoGen, prepared by the author for correspondence. The procedures for determining how many and what the coefficients of each contrast are and how to calculate some CMO’s are indicated. A combined analysis of variance and CMO’s are presented for main factors and for their interactions, but the three statistical packages can generate the analyzes for each trial. With the platform that has been developed in the present study, it will be easier to obtain the decomposition of the effects of main factors and their interactions in an SE under PS based on the construction of an appropriate set of orthogonal polynomials or a combination between these and the CMO’s.
Keywords: Vicia faba L., factorial experiments, fixed effects model, High Valleys of central Mexico.
Reception date: July 2019
Acceptance date: September 2019
Introduction
When designing and analyzing experiments, analysis of variance (Anava) has been conventionally used to minimize experimental error and reliably estimate the effects between treatments (Juarez and Corona, 1990; Sahagún and Frey, 1990; Sahagún, 1997; Meneses et al., 2004). The assumptions that must be satisfied is that the chosen linear model adequately describes the observations, and that the errors follow a normal and independent distribution, with zero mean and constant variance, although unknown (Sahagún, 1990; Sahagún et al., 2008).
The analysis of quantitative variables in fixed, random or mixed effects models can refer to balanced or unbalanced cases (Matzinger et al., 1959; Sahagun, 1998; Montgomery, 2010) with qualitative or quantitative factors such as fertilization, planting density or population , insecticides, fungicides, plant hormones, cultivars, localities, years or their combinations, among others (Sahagún and Frey, 1990; Sahagún, 1997; Meneses et al., 2004; González et al., 2007).
Factorial experiments save resources, increase the accuracy of estimates of mean effects and make possible the study of their interactions (Sahagún et al., 2008). The use of crossing plans and experimental designs is a common procedure in plant and animal genetic improvement (Matzinger et al., 1959; Sahagun, 1997), as well as in seed production, generation, application, transfer and validation of technology (Sahagun and Frey, 1990; Meneses et al., 2004; González et al., 2007; Torres et al., 2017).
Anava is a prerequisite in the comparison of treatment means, but its effects can also be divided into mutually orthogonal contrasts (CMO’s) when one of the four basic experimental designs is chosen or when the series of experiments in time and space are applied with arrangements in strips and divided plots (Gomez and Gomez, 1984; Martínez, 1988; Sahagún, 1998; Rebolledo, 2002). The formation of CMO’s has these advantages: a) each hypothesis test provides new, independent information; b) the interpretation of results is simpler; and c) the maximum estimated number is limited.
In its construction the basic guide is its congruence with the objectives of the research, no matter if they are mutually orthogonal or not, or how many treatments are evaluated (Sahagún et al., 2008). In incomplete factories the interactions of greater degree have been used as experimental error, although it is not common to experiment with more than four factors and it is not frequent that all their interactions are significant (Sahagún et al., 2008; Montgomery, 2010; Walpole et al., 2012). Genotype x environment interaction, orthogonal polynomials, different regression techniques and various multivariate methods also use ANAVA (Gomez and Gomez, 1984; Sahagún, 1990; Sahagún et al., 2008; Torres et al., 2017).
The randomized complete block SE (DBCA) in divided plots is described in many publications, such as Martinez (1988); Rebolledo (2002) who also developed several programs for the SAS to generate Anava, the comparison of treatment means with the test of Tukey and the CMO’s. The linear model of an SE in DBCA under PS was described by Herrera (2011) and Padilla et al. (2019) but there is still little information for random and mixed models and particularly when two factors are housed in a large, medium or small plot (Villa et al., 2010).
The analysis of an SE in subdivided plots is subject to more errors when many variables have been recorded, but the development of programs for InfoStat, InfoGen and SAS, among others, will save time and effort if the linear model chosen is correct (Sahagún, 1998; Herrera, 2011; Padilla et al., 2019). The objective of this study was to present programs to analyze an SE in PS in DBCA with CMO’s using three statistical packages of common use.
Framework
Linear model
It is established that: i= 1, 2, 3, ..., and experiments; j= 1, 2, 3,…, r repetitions; k= 1, 2, 3,… at levels on a large plot; l= 1, 2, 3,…, b levels in medium plot; m= 1, 2, 3,…, c levels in small plot. Thus:
Yijklm = µ + αi + βj(i) + γk + (αγ)ik + εijk + δl + (γδ)kl + (αδ)il + (αγδ)ikl + εijkl + θm + (γθ)km + (δθ)lm + (γδθ)klm + (αθ)im + (αγθ)ikm + (αδθ)ilm + εijklm
Where: µ is the great arithmetic mean; αi is the ith experiment; βj(i) is the j-th repetition nested in the ith experiment; γk is the k-th fertilization; δl is 1-th population density; θm is the m-th cultivar; εijk, εijkl and εijklm are the errors a, b and c of large, medium and small plot, the remaining ten components are viable interactions (Herrera, 2011; Padilla et al., 2019).
Obtaining CMO coefficients
Gomez and Gomez (1984); Sahagún et al. (2008) define an orthogonal contrast as a linear combination of treatment effects. If T1, T2, T3, Tt are unknown parameters related to the effects of t treatments and C1, C2, C3, Ct are known constants, called coefficients of contrasts, in monofactorial experiments, each contrast (Li) is calculated as:
Li = C1T1 + C2T2 + C3T3 + , … , CtTt = with restriction
The sum of squares (SC) of Li with a degree of freedom (gl) is calculated as:
With t treatments there are t-1 orthogonal contrasts. To test its statistical significance in a fixed effects model, the ratio that results from dividing SC Li by SC of the error is compared. The F test is used (1, degrees of freedom of error), at the level of significance chosen (p= 0.05 or p= 0.01).
Two contrasts, L1 and L2, with a degree of freedom (GL), are mutually orthogonal if the sum of the cross products of their coefficients is equal to zero; that is to say:
L1 = C11T1 + C12T2 + C13T3+,…,+C1tTt
L2 = C21T1 + C22T2 + C23T3+,…,+C2tTt
p contrasts with a GL (p>2) are mutually orthogonal if each pair and all pairs in the group are orthogonal. Since the maximum number of mutually orthogonal contrasts with a GL is equal to the number of treatments GL then:
SCL1 + SCL2+SCL3 +, + SCLt-1= SC of treatments
To calculate the coefficients of mutually orthogonal contrasts (CMO) in the interactions of any order in factorial experiments, proceed as follows: 1. To determine how many coefficients there will be, multiply the CMO number of each factor; 2. The coefficients for each interaction are obtained as the product of their values and signs; and 3. All the coefficients of each contrast are captured in the SAS editor program or in the InfoStat or InfoGen dialog. 4. The program is run, the outputs are verified, a receipt is made or the outputs are printed.
With 5 and 2 CMO for factors A and B there will be 10 possibilities. Since there are 6 or 3 coefficients in factors A or B, any CMO will have 18 coefficients. If the coefficients of the first contrast for factors A and B are (1 -1 1 -1 1 -1) and [ -1 2 -1], the first combination with values: (1 -1 1 -1 1 -1) [ -1 2 -1] will produce -1 2 -1 1 -2 1 -1 2 -1 1 -2 1 -1 2 -1 1 -2 1.
Note: multiply 1(-1), 1(2), 1(-1), -1(-1), -1(2), -1(-1), …, -1(-1), -1(2), -1(-1).
For AxC there will also be 10 cases, with 18 coefficients each; its values and signs are equal to those of A1B1. Thus: (1 -1 1 -1 1 -1) [ -1 2 -1] = -1 2 -1 1 -2 1 -1 2 -1 1 -2 1 -1 2 -1 1 -2 1.
For the BxC interaction, 3x3 = 9 coefficients must be obtained for each of the four CMOs. For B1C1 you will have: [ -1 2 -1] [ -1 2 -1] = 1 -2 1 -2 4 -2 1 -2 1.
Note: each value is obtained as -1(-1), -1(2), -1(-1), 2(-1), 2(2), 2(-1), -1(-1), -1(2), -1(-1).
In AxBxC, there are 6x3x3= 54 coefficients for each of the 5x2x2= 20 mutually orthogonal contrasts. For SAS its values and signs are obtained by multiplying the coefficients of each AxB interaction with those of C, but for InfoStat these are generated by multiplying the values of C by those of AxB. For SAS:
In A1B1C1 its values are the product of ( -1 2 -1 1 -2 1 -1 2 -1 1 -2 1 -1 2 -1 1 -2 1) with [ -1 2 -1] = 1 -2 1 -2 4 -2 1 -2 1 -1 2 -1 2 -4 2 -1 2 -1 1 -2 1 -2 4 -2 1 -2 1 -1 2 -1 2 -4 2 -1 2 -1 1 -2 1 -2 4 -2 1 -2 1 -1 2 -1 2 -4 2 -1 2 -1.
Statistical analysis
The pod weights in green were subjected to a combined analysis of variance. Algebraic procedures are described in Herrera (2011); Padilla et al. (2019). The outputs were obtained with the versions described in SAS Institute (1989); InfoStat (Balzarini et al., 2008; Di Rienzo et al., 2008) and InfoGen (Balzarini and Di Rienzo, 2016). Additionally, a subdivision of the three main effects and their four interactions with mutually orthogonal contrasts was made (Gomez and Gomez, 1984).
Calculation of some CMO
In Padilla et al. (2019) shows the performance data in green pod used to perform the following calculations. With the totals of AxB, AxC and AxBxC, the CMOs for the three factors and for the BxC interaction can be calculated.
Contrast 1 of factor A (FER)
SC L1 = = = = 86
Contrast 1 of factor B (DEN)
SCL1 = = = = 2.245
Contrast 1 of factor C (CUL)
SCL1 = = = = 11.54
Contrast 1 of the interaction FER x DEN (AxB)
SCL1 = , where: e, c and r are localities, cultivars and repetitions, respectively.
= [81.81 – 70.94 + 108.36 – 79.72 + 82.8 – 72.57 -2(128.61) + 2(137.40) – 2(147.09) + 2(113.16)
-2(143.56) + 2(113.56) + 154.69 – 116.72 + 208.03 – 151.22 + 184.50 – 167.23]2 / [2(3)(3)(36)]
= (1548.43 – 1546.92)2 / 648 = 0.0035.
Contrast 1 of the FER x CUL (AxC) interaction.
SCL1 = , where: b are the density levels of population.
= = 8.31
Contrast 1 of the DEN x CUL interaction (B x C).
SCL1 = , where: a are the levels of fertilization.
= = 5.53.
Contrast 1 of the interaction FER x DEN x CUL (AxBxC).
SCL1 =
=
= 0.91.
The above calculations and the rest of the CMOs that are possible to estimate can be obtained with the following routine:
Programs for InfoStat and InfoGen
Stage 1
The data is ordered as experiments (EXP), repetitions (REP), fertilization (FER), population density (DEN), cultivars (CUL) and variables (s).
Stage 2
In the main menu choose statistics\analysis of variance; In the define dialog box: Dependent variables: RVV. Classification variables: EXP REP FER DEN CUL, Choose accept.
Stage 3
In specifications of the terms of the model write:
EXP\EXP>REP*FER; EXP>REP\EXP>REP*FER; FER\EXP>REP*FER; EXP*FER\EXP>REP*FER;
EXP>REP*FER;DEN\EXP>FER>REP*DEN;DEN*EXP\EXP>FER>REP*DEN;DEN*FER\EXP>FER>REP*DEN;DEN*EXP*FER\EXP>FER>REP*DEN;EXP>FER>REP*DEN;CUL;CUL*EXP;CUL*FER;
CUL*DEN;CUL*EXP*FER;CUL*EXP*DEN;CUL*FER*DEN; choose accept.
Note: in the dialog box the instructions above must be written separately on each line and without the semicolon.
Step 4
In the dialog box that shows Analysis of variance choose: comparisons\contrasts\treatments\choose effects\matrix of contrasts\accept.
Before clicking on accept, you must choose to control orthogonality. After defining whether a main effect or an interaction will be estimated, enter the coefficients in the contrast matrix.
SAS Program
In the database Exp= localities, A, B and C are fertilization, population density and cultivars and the variables are identified as X1, X2, X16.
Data fava bean;
Input Exp rep A B C X1 X2 X3 X4 X5 X6 X7 X8 X9 X10 X11 X12 X13 X14 X15 X16;
Cards;
Here the data is captured in the order of the input.
PROC SORT; BY EXP; PROC GLM; BY EXP; CLASS REP A B C;
MODEL X1-X16= REP A REP*A B A*B REP*B(A) C A*C B*C A*B*C;
TEST H=REP A E=REP*A;
TEST H=B A*B E=REP*B(A);
An analysis of individual variance with glm is generated and mutually orthogonal contrasts are calculated for main effects, large and medium plot errors are used for f tests.
CONTRAST 'A1, A3,A5 vs A2,A4,A6' A 1 -1 1 -1 1 -1/E=REP*A;
CONTRAST 'A1 vs A3, A5' A 2 0 -1 0 -1 0/E=REP*A;
CONTRAST 'A3 vs A5' A 0 0 1 0 -1 0/E=REP*A;
CONTRAST 'A2 vs A4, A6' A 0 2 0 -1 0 -1/E= REP *A;
CONTRAST 'A4 vs A6' A 0 0 0 1 0 -1/E=REP*A;
CONTRAST 'B2 vs B1, B3' B -1 2 -1/E=REP*B(A);
CONTRAST 'B1 vs B3' B 1 0 -1/E=REP*B(A);
The contrasts of factor c are tested with the residual of the model, which is the small plot error; they do not need to be specified at the end.
CONTRAST 'C2 vs C1, C3' C -1 2 -1;
CONTRAST 'C1 vs C3' C 1 0 -1;
The contrasts of the axb interaction are tested with the median plot error.
CONTRAST 'A1B1' A*B -1 2 -1 1 -2 1 -1 2 -1 1 -2 1 -1 2 -1 1 -2 1/E=REP*B(A);
CONTRAST 'A2B1' A*B -2 4 -2 0 0 0 1 -2 1 0 0 0 1 -2 1 0 0 0/E=REP*B(A);
CONTRAST 'A3B1' A*B 0 0 0 0 0 0 -1 2 -1 0 0 0 1 -2 1 0 0 0/E=REP*B(A);
CONTRAST 'A4B1' A*B 0 0 0 -2 4 -2 0 0 0 1 -2 1 0 0 0 1 -2 1/E=REP*B(A);
CONTRAST 'A5B1' A*B 0 0 0 0 0 0 0 0 0 -1 2 -1 0 0 0 1 -2 1/E=REP*B(A);
CONTRAST 'A1B2' A*B 1 0 -1 -1 0 1 1 0 -1 -1 0 1 1 0 -1 -1 0 1/E=REP*B(A);
CONTRAST 'A2B2' A*B 2 0 -2 0 0 0 -1 0 1 0 0 0 -1 0 1 0 0 0/E=REP*B(A);
CONTRAST 'A3B2' A*B 0 0 0 0 0 0 1 0 -1 0 0 0 -1 0 1 0 0 0/E=REP*B(A);
CONTRAST 'A4B2' A*B 0 0 0 2 0 -2 0 0 0 -1 0 1 0 0 0 -1 0 1/E=REP*B(A);
CONTRAST 'A5B2' A*B 0 0 0 0 0 0 0 0 0 1 0 -1 0 0 0 -1 0 1/E=REP*B(A);
The errors of the axc interaction are tested with the residual of the model, so they do not need to be indicated at the end.
CONTRAST 'A1C1' A*C -1 2 -1 1 -2 1 -1 2 -1 1 -2 1 -1 2 -1 1 -2 1;
CONTRAST 'A2C1' A*C -2 4 -2 0 0 0 1 -2 1 0 0 0 1 -2 1 0 0 0;
CONTRAST 'A3C1' A*C 0 0 0 0 0 0 -1 2 -1 0 0 0 1 -2 1 0 0 0;
CONTRAST 'A4C1' A*C 0 0 0 -2 4 -2 0 0 0 1 -2 1 0 0 0 1 -2 1;
CONTRAST 'A5C1' A*C 0 0 0 0 0 0 0 0 0 -1 2 -1 0 0 0 1 -2 1;
CONTRAST 'A1C2' A*C 1 0 -1 -1 0 1 1 0 -1 -1 0 1 1 0 -1 -1 0 1;
CONTRAST 'A2C2' A*C 2 0 -2 0 0 0 -1 0 1 0 0 0 -1 0 1 0 0 0;
CONTRAST 'A3C2' A*C 0 0 0 0 0 0 1 0 -1 0 0 0 -1 0 1 0 0 0;
CONTRAST 'A4C2' A*C 0 0 0 2 0 -2 0 0 0 -1 0 1 0 0 0 -1 0 1;
CONTRAST 'A5C2' A*C 0 0 0 0 0 0 0 0 0 1 0 -1 0 0 0 -1 0 1;
CONTRAST 'B1C1' B*C 1 -2 1 -2 4 -2 1 -2 1;
CONTRAST 'BIC2' B*C -1 0 1 2 0 -2 -1 0 1;
CONTRAST 'B2C1' B*C -1 2 -1 0 0 0 1 -2 1;
CONTRAST 'B2C2' B*C 1 0 -1 0 0 0 -1 0 1;
The axbxc interaction coefficients are tested with the small or residual plot error of the model and are not indicated at the end.
CONTRAST 'A1B1C1' A*B*C 1 -2 1 -2 4 -2 1 -2 1 -1 2 -1 2 -4 2 -1 2 -1 1 -2 1 -2 4 -2 1 -2 1 -1 2 -1 2 -4 2 -1 2 -1 1 -2 1 -2 4 -2 1 -2 1 -1 2 -1 2 -4 2 -1 2 -1;
CONTRAST 'A1B1C2' A*B*C -1 0 1 2 0 -2 -1 0 1 1 0 -1 -2 0 2 1 0 -1 -1 0 1 2 0 -2 -1 0 1 1 0 -1 -2 0 2 1 0 -1 -1 0 1 2 0 -2 -1 0 1 1 0 -1 -2 0 2 1 0 -1;
CONTRAST 'A1B2C1' A*B*C -1 2 -1 0 0 0 1 -2 1 1 -2 1 0 0 0 -1 2 -1 -1 2 -1 0 0 0 1 -2 1 1 -2 1 0 0 0 -1 2 -1 -1 2 -1 0 0 0 1 -2 1 1 -2 1 0 0 0 -1 2 -1;
CONTRAST 'A1B2C2' A*B*C 1 0 -1 0 0 0 -1 0 1 -1 0 1 0 0 0 1 0 -1 1 0 -1 0 0 0 -1 0 1 -1 0 1 0 0 0 1 0 -1 1 0 -1 0 0 0 -1 0 1 -1 0 1 0 0 0 1 0 -1;
CONTRAST 'A2B1C1' A*B*C 2 -4 2 -4 8 -4 2 -4 2 0 0 0 0 0 0 0 0 0 -1 2 -1 2 -4 2 -1 2 -1 0 0 0 0 0 0 0 0 0 -1 2 -1 2 -4 2 -1 2 -1 0 0 0 0 0 0 0 0 0;
CONTRAST 'A2B1C2' A*B*C -2 0 2 4 0 -4 -2 0 2 0 0 0 0 0 0 0 0 0 1 0 -1 -2 0 2 1 0 -1 0 0 0 0 0 0 0 0 0 1 0 -1 -2 0 2 1 0 -1 0 0 0 0 0 0 0 0 0;
CONTRAST 'A2B2C1' A*B*C -2 4 -2 0 0 0 2 -4 2 0 0 0 0 0 0 0 0 0 1 -2 1 0 0 0 -1 2 -1 0 0 0 0 0 0 0 0 0 1 -2 1 0 0 0 -1 2 -1 0 0 0 0 0 0 0 0 0;
CONTRAST 'A2B2C2' A*B*C 2 0 -2 0 0 0 -2 0 2 0 0 0 0 0 0 0 0 0 -1 0 1 0 0 0 1 0 -1 0 0 0 0 0 0 0 0 0 -1 0 1 0 0 0 1 0 -1 0 0 0 0 0 0 0 0 0;
CONTRAST 'A3B1C1' A*B*C 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 -2 1 -2 4 -2 1 -2 1 0 0 0 0 0 0 0 0 0 -1 2 -1 2 -4 2 -1 2 -1 0 0 0 0 0 0 0 0 0;
CONTRAST 'A3B1C2' A*B*C 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 -1 0 1 2 0 -2 -1 0 1 0 0 0 0 0 0 0 0 0 1 0 -1 -2 0 2 1 0 -1 0 0 0 0 0 0 0 0 0;
CONTRAST 'A3B2C1' A*B*C 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 -1 2 -1 0 0 0 1 -2 1 0 0 0 0 0 0 0 0 0 1 -2 1 0 0 0 -1 2 -1 0 0 0 0 0 0 0 0 0;
CONTRAST 'A3B2C2' A*B*C 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 -1 0 0 0 -1 0 1 0 0 0 0 0 0 0 0 0 -1 0 1 0 0 0 1 0 -1 0 0 0 0 0 0 0 0 0;
CONTRAST 'A4B1C1' A*B*C 0 0 0 0 0 0 0 0 0 2 -4 2 -4 8 -4 2 -4 2 0 0 0 0 0 0 0 0 0 -1 2 -1 2 -4 2 -1 2 -1 0 0 0 0 0 0 0 0 0 -1 2 -1 2 -4 2 -1 2 -1;
CONTRAST 'A4B1C2' A*B*C 0 0 0 0 0 0 0 0 0 -2 0 2 4 0 -4 -2 0 2 0 0 0 0 0 0 0 0 0 1 0 -1 -2 0 2 1 0 -1 0 0 0 0 0 0 0 0 0 1 0 -1 -2 0 2 1 0 -1;
CONTRAST 'A4B2C1' A*B*C 0 0 0 0 0 0 0 0 0 -2 4 -2 0 0 0 2 -4 2 0 0 0 0 0 0 0 0 0 1 -2 1 0 0 0 -1 2 -1 0 0 0 0 0 0 0 0 0 1 -2 1 0 0 0 -1 2 -1;
CONTRAST 'A4B2C2' A*B*C 0 0 0 0 0 0 0 0 0 2 0 -2 0 0 0 -2 0 2 0 0 0 0 0 0 0 0 0 -1 0 1 0 0 0 1 0 -1 0 0 0 0 0 0 0 0 0 -1 0 1 0 0 0 1 0 -1;
CONTRAST 'A5B1C1' A*B*C 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 -2 1 -2 4 -2 1 -2 1 0 0 0 0 0 0 0 0 0 -1 2 -1 2 -4 2 -1 2 -1;
CONTRAST 'A5B1C2' A*B*C 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 -1 0 1 2 0 -2 -1 0 1 0 0 0 0 0 0 0 0 0 1 0 -1 -2 0 2 1 0 -1;
CONTRAST 'A5B2C1' A*B*C 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 -1 2 -1 0 0 0 1 -2 1 0 0 0 0 0 0 0 0 0 1 -2 1 0 0 0 -1 2 -1;
CONTRAST 'A5B2C2' A*B*C 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 -1 0 0 0 -1 0 1 0 0 0 0 0 0 0 0 0 -1 0 1 0 0 0 1 0 -1;
PROC GLM; CLASS EXP REP A B C;
MODEL X1-X16= EXP REP(EXP) A A*EXP REP*A(EXP) B A*B B*EXP A*B*EXP REP*B(A EXP) C A*C B*C A*B*C C*EXP A*C*EXP B*C*EXP;
TEST H= EXP A REP(EXP) EXP*A E=REP*A(EXP);
TEST H= B A*B B*EXP A*B*EXP E=REP*B(A EXP);
A combined analysis of variance is obtained with partition of main effects with mutually orthogonal contrasts.
CONTRAST 'A1, A3, A5 VS A2, A4, A6' A 1 -1 1 -1 1 -1/E=REP*A(EXP);
CONTRAST 'A1 VS A3, A5' A 2 0 -1 0 -1 0/E=REP*A(EXP);
CONTRAST 'A3 VS A5' A 0 0 1 0 -1 0/E=REP*A(EXP);
CONTRAST 'A2 VS A4, A6' A 0 2 0 -1 0 -1/E=REP*A(EXP);
CONTRAST 'A4 VS A6' A 0 0 0 1 0 -1/E=REP*A(EXP);
CONTRAST 'B2 VS B1, B3' B -1 2 -1/E=REP*B(A EXP);
CONTRAST 'B1 VS B3' B 1 0 -1/E=REP*B(A EXP);
CONTRAST 'C2 VS C1, C3' C -1 2 -1;
CONTRAST 'C1 VS C3' C 1 0 -1;
CONTRAST 'A1B1' A*B -1 2 -1 1 -2 1 -1 2 -1 1 -2 1 -1 2 -1 1 -2 1/E=REP*B(A EXP);
CONTRAST 'A2B1' A*B -2 4 -2 0 0 0 1 -2 1 0 0 0 1 -2 1 0 0 0/E=REP*B(A EXP);
CONTRAST 'A3B1' A*B 0 0 0 0 0 0 -1 2 -1 0 0 0 1 -2 1 0 0 0/E=REP*B(A EXP);
CONTRAST 'A4B1' A*B 0 0 0 -2 4 -2 0 0 0 1 -2 1 0 0 0 1 -2 1/E=REP*B(A EXP);
CONTRAST 'A5B1' A*B 0 0 0 0 0 0 0 0 0 -1 2 -1 0 0 0 1 -2 1/E=REP*B(A EXP);
CONTRAST 'A1B2' A*B 1 0 -1 -1 0 1 1 0 -1 -1 0 1 1 0 -1 -1 0 1/E=REP*B(A EXP);
CONTRAST 'A2B2' A*B 2 0 -2 0 0 0 -1 0 1 0 0 0 -1 0 1 0 0 0/E=REP*B(A EXP);
CONTRAST 'A3B2' A*B 0 0 0 0 0 0 1 0 -1 0 0 0 -1 0 1 0 0 0/E=REP*B(A EXP);
CONTRAST 'A4B2' A*B 0 0 0 2 0 -2 0 0 0 -1 0 1 0 0 0 -1 0 1/E=REP*B(A EXP);
CONTRAST 'A5B2' A*B 0 0 0 0 0 0 0 0 0 1 0 -1 0 0 0 -1 0 1/E=REP*B(A EXP);
CONTRAST 'A1C1' A*C -1 2 -1 1 -2 1 -1 2 -1 1 -2 1 -1 2 -1 1 -2 1;
CONTRAST 'A2C1' A*C -2 4 -2 0 0 0 1 -2 1 0 0 0 1 -2 1 0 0 0;
CONTRAST 'A3C1' A*C 0 0 0 0 0 0 -1 2 -1 0 0 0 1 -2 1 0 0 0;
CONTRAST 'A4C1' A*C 0 0 0 -2 4 -2 0 0 0 1 -2 1 0 0 0 1 -2 1;
CONTRAST 'A5C1' A*C 0 0 0 0 0 0 0 0 0 -1 2 -1 0 0 0 1 -2 1;
CONTRAST 'A1C2' A*C 1 0 -1 -1 0 1 1 0 -1 -1 0 1 1 0 -1 -1 0 1;
CONTRAST 'A2C2' A*C 2 0 -2 0 0 0 -1 0 1 0 0 0 -1 0 1 0 0 0;
CONTRAST 'A3C2' A*C 0 0 0 0 0 0 1 0 -1 0 0 0 -1 0 1 0 0 0;
CONTRAST 'A4C2' A*C 0 0 0 2 0 -2 0 0 0 -1 0 1 0 0 0 -1 0 1;
CONTRAST 'A5C2' A*C 0 0 0 0 0 0 0 0 0 1 0 -1 0 0 0 -1 0 1;
CONTRAST 'B1C1' B*C 1 -2 1 -2 4 -2 1 -2 1;
CONTRAST 'BIC2' B*C -1 0 1 2 0 -2 -1 0 1;
CONTRAST 'B2C1' B*C -1 2 -1 0 0 0 1 -2 1;
CONTRAST 'B2C2' B*C 1 0 -1 0 0 0 -1 0 1;
CONTRAST 'A1B1C1' A*B*C 1 -2 1 -2 4 -2 1 -2 1 -1 2 -1 2 -4 2 -1 2 -1 1 -2 1 -2 4 -2 1 -2 1 -1 2 -1 2 -4 2 -1 2 -1 1 -2 1 -2 4 -2 1 -2 1 -1 2 -1 2 -4 2 -1 2 -1;
CONTRAST 'A1B1C2' A*B*C -1 0 1 2 0 -2 -1 0 1 1 0 -1 -2 0 2 1 0 -1 -1 0 1 2 0 -2 -1 0 1 1 0 -1 -2 0 2 1 0 -1 -1 0 1 2 0 -2 -1 0 1 1 0 -1 -2 0 2 1 0 -1;
CONTRAST 'A1B2C1' A*B*C -1 2 -1 0 0 0 1 -2 1 1 -2 1 0 0 0 -1 2 -1 -1 2 -1 0 0 0 1 -2 1 1 -2 1 0 0 0 -1 2 -1 -1 2 -1 0 0 0 1 -2 1 1 -2 1 0 0 0 -1 2 -1;
CONTRAST 'A1B2C2' A*B*C 1 0 -1 0 0 0 -1 0 1 -1 0 1 0 0 0 1 0 -1 1 0 -1 0 0 0 -1 0 1 -1 0 1 0 0 0 1 0 -1 1 0 -1 0 0 0 -1 0 1 -1 0 1 0 0 0 1 0 -1;
CONTRAST 'A2B1C1' A*B*C 2 -4 2 -4 8 -4 2 -4 2 0 0 0 0 0 0 0 0 0 -1 2 -1 2 -4 2 -1 2 -1 0 0 0 0 0 0 0 0 0 -1 2 -1 2 -4 2 -1 2 -1 0 0 0 0 0 0 0 0 0;
CONTRAST 'A2B1C2' A*B*C -2 0 2 4 0 -4 -2 0 2 0 0 0 0 0 0 0 0 0 1 0 -1 -2 0 2 1 0 -1 0 0 0 0 0 0 0 0 0 1 0 -1 -2 0 2 1 0 -1 0 0 0 0 0 0 0 0 0;
CONTRAST 'A2B2C1' A*B*C -2 4 -2 0 0 0 2 -4 2 0 0 0 0 0 0 0 0 0 1 -2 1 0 0 0 -1 2 -1 0 0 0 0 0 0 0 0 0 1 -2 1 0 0 0 -1 2 -1 0 0 0 0 0 0 0 0 0;
CONTRAST 'A2B2C2' A*B*C 2 0 -2 0 0 0 -2 0 2 0 0 0 0 0 0 0 0 0 -1 0 1 0 0 0 1 0 -1 0 0 0 0 0 0 0 0 0 -1 0 1 0 0 0 1 0 -1 0 0 0 0 0 0 0 0 0;
CONTRAST 'A3B1C1' A*B*C 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 -2 1 -2 4 -2 1 -2 1 0 0 0 0 0 0 0 0 0 -1 2 -1 2 -4 2 -1 2 -1 0 0 0 0 0 0 0 0 0;
CONTRAST 'A3B1C2' A*B*C 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 -1 0 1 2 0 -2 -1 0 1 0 0 0 0 0 0 0 0 0 1 0 -1 -2 0 2 1 0 -1 0 0 0 0 0 0 0 0 0;
CONTRAST 'A3B2C1' A*B*C 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 -1 2 -1 0 0 0 1 -2 1 0 0 0 0 0 0 0 0 0 1 -2 1 0 0 0 -1 2 -1 0 0 0 0 0 0 0 0 0;
CONTRAST 'A3B2C2' A*B*C 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 -1 0 0 0 -1 0 1 0 0 0 0 0 0 0 0 0 -1 0 1 0 0 0 1 0 -1 0 0 0 0 0 0 0 0 0;
CONTRAST 'A4B1C1' A*B*C 0 0 0 0 0 0 0 0 0 2 -4 2 -4 8 -4 2 -4 2 0 0 0 0 0 0 0 0 0 -1 2 -1 2 -4 2 -1 2 -1 0 0 0 0 0 0 0 0 0 -1 2 -1 2 -4 2 -1 2 -1;
CONTRAST 'A4B1C2' A*B*C 0 0 0 0 0 0 0 0 0 -2 0 2 4 0 -4 -2 0 2 0 0 0 0 0 0 0 0 0 1 0 -1 -2 0 2 1 0 -1 0 0 0 0 0 0 0 0 0 1 0 -1 -2 0 2 1 0 -1;
CONTRAST 'A4B2C1' A*B*C 0 0 0 0 0 0 0 0 0 -2 4 -2 0 0 0 2 -4 2 0 0 0 0 0 0 0 0 0 1 -2 1 0 0 0 -1 2 -1 0 0 0 0 0 0 0 0 0 1 -2 1 0 0 0 -1 2 -1;
CONTRAST 'A4B2C2' A*B*C 0 0 0 0 0 0 0 0 0 2 0 -2 0 0 0 -2 0 2 0 0 0 0 0 0 0 0 0 -1 0 1 0 0 0 1 0 -1 0 0 0 0 0 0 0 0 0 -1 0 1 0 0 0 1 0 -1;
CONTRAST 'A5B1C1' A*B*C 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 -2 1 -2 4 -2 1 -2 1 0 0 0 0 0 0 0 0 0 -1 2 -1 2 -4 2 -1 2 -1;
CONTRAST 'A5B1C2' A*B*C 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 -1 0 1 2 0 -2 -1 0 1 0 0 0 0 0 0 0 0 0 1 0 -1 -2 0 2 1 0 -1;
CONTRAST 'A5B2C1' A*B*C 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 -1 2 -1 0 0 0 1 -2 1 0 0 0 0 0 0 0 0 0 1 -2 1 0 0 0 -1 2 -1;
CONTRAST 'A5B2C2' A*B*C 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 -1 0 0 0 -1 0 1 0 0 0 0 0 0 0 0 0 -1 0 1 0 0 0 1 0 -1;
RUN;
Some results obtained with the three statistical packages.
Source of variation | Degrees of freedom | Sum of squares | Squares means | F value | p value |
Model | 159 | 4 571.71 | 28.75 | 6.58 | 0.0001 |
Experiments (Exp) | 1 | 37.13 | 37.13 | 3.7 | 0.0686 |
Rep (Exp) | 4 | 1 650.68 | 412.67 | 41.16 | 0.0001 |
Fertilization (Fer) | 5 | 185.09 | 37.02 | 3.69 | 0.0157 |
Exp x Fer | 5 | 150.73 | 30.15 | 3.01 | 0.0349 |
Error a | 20 | 200.5 | 10.02 | 2.29 | |
Density (Den) | 2 | 1 333.63 | 666.63 | 61.46 | 0.0001 |
Fer x Den | 10 | 49.90 | 4.99 | 0.46 | 0.9073 |
Exp x Den | 2 | 67.69 | 33.84 | 3.12 | 0.0532 |
Exp x Fer x Den | 10 | 106.91 | 10.69 | 0.99 | 0.4684 |
Error b | 48 | 520.61 | 10.85 | 2.48 | |
Cultivars (Cul) | 2 | 33.85 | 16.92 | 3.87 | 0.0228 |
Cul x Fer | 10 | 50.63 | 5.06 | 1.16 | 0.3228 |
Cul x Den | 4 | 7.92 | 1.98 | 0.45 | 0.7703 |
Cul x Fer x Den | 20 | 59.49 | 2.97 | 0.68 | 0.8416 |
Cul x Exp | 2 | 56.25 | 28.13 | 6.43 | 0.002 |
Cul x Exp x Fer | 10 | 53.98 | 5.40 | 1.23 | 0.2725 |
Cul x Exp x Den | 4 | 7.08 | 1.77 | 0.41 | 0.8048 |
Error c | 164 | 716.96 | 4.37 | ||
Total | 323 | 5 288.67 |
Mutually orthogonal contrasts for fertilization (large plot).
Fer (A) | Degrees of freedom | Sum of squares | F value | p value | Large plot error |
A1 | 1 | 86.01 | 8.58 | 0.0083 | Exp>Rep>Fer |
A2 | 1 | 64.11 | 6.39 | 0.02 | Exp>Rep>Fer |
A3 | 1 | 25.64 | 2.56 | 0.1255 | Exp>Rep>Fer |
A4 | 1 | 8.56 | 0.85 | 0.3665 | Exp>Rep>Fer |
A5 | 1 | 0.79 | 0.08 | 0.7813 | Exp>Rep>Fer |
Total | 5 | 185.1 | 3.69 | 0.0157 | Exp>Rep>Fer |
Mutually orthogonal contrasts for population density (medium plot).
Den (B) | Degrees of freedom | Sum of squares | F value | p value | Medium plot error |
B1 | 1 | 2.25 | 0.21 | 0.65 | Exp>Fer>Rep*Den |
B2 | 1 | 1 331.02 | 122.72 | 0.001 | Exp>Fer>Rep*Den |
Total | 2 | 1 333.27 | 61.46 | 0.0001 | Exp>Fer>Rep*Den |
Mutually orthogonal contrasts for fava bean cultivars (small plot).
Cul (C) | Degrees of freedom | Sum of squares | F value | p value | Small plot error |
C1 | 1 | 11.54 | 2.64 | 0.1061 | Model Residual |
C2 | 1 | 22.3 | 5.0 | 0.0252 | Model Residual |
Total | 2 | 33.84 | 3.87 | 0.0228 | Model Residual |
Mutually orthogonal contrasts for the fertilization x density interaction (AxB).
DenxFer or AxB | Degrees of freedom | Sum of squares | F value | p value | Interaction error |
C1 | 1 | 0.003 | 0.0003 | 0.98 | Exp>Fer>Rep*Den |
C2 | 1 | 2.96 | 0.27 | 0.6 | Exp>Fer>Rep*Den |
C3 | 1 | 8.18 | 0.75 | 0.38 | Exp>Fer>Rep*Den |
C4 | 1 | 12.94 | 1.19 | 0.28 | Exp>Fer>Rep*Den |
C5 | 1 | 0.3 | 0.03 | 0.86 | Exp>Fer>Rep*Den |
C6 | 1 | 0.7 | 0.6 | 0.8 | Exp>Fer>Rep*Den |
C7 | 1 | 14.32 | 1.32 | 0.25 | Exp>Fer>Rep*Den |
C8 | 1 | 0.06 | 0.01 | 0.94 | Exp>Fer>Rep*Den |
C9 | 1 | 2.99 | 0.28 | 0.6 | Exp>Fer>Rep*Den |
C10 | 1 | 7.45 | 0.69 | 0.41 | Exp>Fer>Rep*Den |
Total | 10 | 49.9 | 0.9 | 0.90 | Exp>Fer>Rep*Den |
Mutually orthogonal contrasts for the interaction fertilization x cultivars or AxC.
CulxFer or AxC | Degrees of freedom | Sum of squares | F value | p value | Interaction Error |
C1 | 1 | 8.31 | 1.9 | 0.16 | Model Residual |
C2 | 1 | 0.05 | 0.01 | 0.91 | Model Residual |
C3 | 1 | 0.14 | 0.03 | 0.85 | Model Residual |
C4 | 1 | 3.08 | 0.71 | 0.4 | Model Residual |
C5 | 1 | 0.02 | 0.004 | 0.94 | Model Residual |
C6 | 1 | 6.94 | 1.59 | 0.2 | Model Residual |
C7 | 1 | 4.51 | 1.03 | 0.31 | Model Residual |
C8 | 1 | 4.35 | 1 | 0.32 | Model Residual |
C9 | 1 | 15.23 | 3.48 | 0.06 | Model Residual |
C10 | 1 | 8.01 | 1.83 | 0.17 | Model Residual |
Total | 10 | 50.64 | 1.16 | 0.32 | Model Residual |
Mutually orthogonal contrasts for the interaction density x cultivars or BxC.
CulxDen or BxC | Degrees of freedom | Sum of squares | F Value | p value | Interaction Error |
C1 | 1 | 5.54 | 1.27 | 0.26 | Model Residual |
C2 | 1 | 0.14 | 0.03 | 0.85 | Model Residual |
C3 | 1 | 1.03 | 0.24 | 0.62 | Model Residual |
C4 | 1 | 1.21 | 0.28 | 0.59 | Model Residual |
Total | 4 | 7.92 | 0.45 | 0.77 | Model Residual |
Mutually orthogonal contrasts for the interaction fertilization x density x cultivars.
CulxDenxFer or AxBxC | Degrees of freedom | Sum of squares | F value | p value | Interaction Error |
C1 | 1 | 0.91 | 0.21 | 0.64 | Model Residual |
C2 | 1 | 3.4 | 0.78 | 0.37 | Model Residual |
C3 | 1 | 14.76 | 3.38 | 0.06 | Model Residual |
C4 | 1 | 0.16 | 0.04 | 0.84 | Model Residual |
C5 | 1 | 0.12 | 0.03 | 0.87 | Model Residual |
C6 | 1 | 0.61 | 0.14 | 0.7 | Model Residual |
C7 | 1 | 2.8 | 0.64 | 0.42 | Model Residual |
C8 | 1 | 2.17 | 0.5 | 0.48 | Model Residual |
C9 | 1 | 8.06 | 1.84 | 0.17 | Model Residual |
C10 | 1 | 7.65 | 1.75 | 0.18 | Model Residual |
C11 | 1 | 2.15 | 0.49 | 0.48 | Model Residual |
C12 | 1 | 0.33 | 0.08 | 0.78 | Model Residual |
C13 | 1 | 0.71 | 0.16 | 0.68 | Model Residual |
C14 | 1 | 1.19 | 0.27 | 0.6 | Model Residual |
C15 | 1 | 0.57 | 0.13 | 0.71 | Model Residual |
C16 | 1 | 1.31 | 0.3 | 0.58 | Model Residual |
C17 | 1 | 0.001 | 0 | 0.98 | Model Residual |
C18 | 1 | 8.12 | 1.86 | 0.17 | Model Residual |
C19 | 1 | 3.65 | 0.84 | 0.36 | Model Residual |
C20 | 1 | 0.81 | 0.18 | 0.66 | Model Residual |
Total | 20 | 59.48 | 0.68 | 0.84 | Model Residual |
Conclusions
The three statistical packages generate similar information for the series of experiments in randomized complete blocks in arrangement of subdivided plots (SE in DBCA in PS) in free or student versions (without cost). The annual license for a PC for SAS is USD $2 000.00 and for InfoStat or InfoGen it is only USD $50.00, the last two are friendlier than SAS, requiring less information to obtain statistical analyzes of interest.
The coefficients of mutually orthogonal contrasts (CMO’s) must be captured in all three software’s, their calculation for interactions is more laborious when the number of levels within each factor increases. The user has the option of constructing only a subset of CMO’s or non-orthogonal, that are congruent with the research objectives. The statistical significance of the F values of the CMO’s could be considered as a practical guide to design other complementary analyzes, such as multiple comparisons of treatment means or the application of multivariate techniques.
With the information presented in this essay, it will be easier to extend your analysis of SE in DBCA in PS in the case of orthogonal polynomials (PO), response surfaces, or combinations of PO with CMO’s.
Cited literature
Balzarini, M. G.; González, L.; Tablada, M.; Casanoves, F.; Di Rienzo, J. A. y Robledo, C. W. 2008. Manual del usuario de InfoStat, Editorial Brujas, Córdoba, Argentina. 82-112 pp.
Balzarini, M. G. y Di Rienzo, J. A. 2016. InfoGen. FCA. Universidad Nacional de Córdoba, Argentina. http://www.info-gen.com.mx.
Di Rienzo, J. A.; Casanoves, F.; Balzarini, M. G.; González, L.; Tablada, M. y Robledo, C. W. 2008. InfoStat, versión 2008. Grupo InfoStat, FCA, Universidad Nacional de Córdoba. Argentina.
Gomez, K. A., Gomez, A. A. 1984. Statistical procedures for agricultural research. 2nd (Ed.). John Wiley & Sons, Inc. Printed in Singarore. 680 p.
González, H. A.; Pérez, L. D. J.; Sahagún, C. J.; Norman, M. T. H.; Balbuena, M. A. y Gutiérrez, R. F. 2007. Análisis de una cruza dialélica completa de líneas endogámicas de maíz. Rev. Cienc. Agríc. Informa. 16(1):10-17.
González, H. A.; Sahagún, C. J. y Pérez, L. D. J. 2007. Estudio de ocho líneas de maíz en un experimento dialélico incompleto. Rev. Cienc. Agríc. Informa. 16(1):3-9.
Herrera, S. L. A. 2011. Análisis de la varianza de un grupo de experimentos en parcelas subdivididas. Revista de la Facultad de Ciencias Veterinarias, UCV. 52(1):59-72.
Juárez, M. J. A. y Corona, S. T. 1990. El análisis de experimentos por el método Papadakis. Rev. Chapingo. 71-72:110-113.
Martínez, G. A. 1988. Diseños experimentales. Métodos y elementos de teoría. Editorial Trillas. Primera Edición. México, DF. 756 p.
Matzinger, D. F.; Sprague, G. F. and Cockerham, C. C. 1959. Diallel Crosses of maize in experiments repeated over locations and years. Agron. J. 51(3):346-350.
Meneses, M.; Mejía I. C. J. A. y Villanueva, V. C. 2004. Cambios en los componentes de varianza genética al realizar selección combinada en una población de calabaza. Rev. Chapingo Ser. Hortic. 10(2):165-172.
Montgomery, D. C. 2010. Diseño y análisis de experimentos. Limusa-Noriega Editores. Segunda Edición, México, DF. 686 p.
Padilla, L. A.; González, H. A.; Pérez, L. D. J.; Rubí, A. M.; Gutiérrez, R. F.; Ramírez, D. J. F.; Franco, M. J. R. P. y Serrato, C. R. 2019. Programas para SAS e InfoStat para analizar una serie de experimentos en parcelas subdivididas. Universidad Autónoma del Estado de México. Primera Edición. Toluca, México. 45- 55 p.
Rebolledo, R. H. H. 2002. Manual SAS por computadora. Análisis estadístico de datos experimentales. Editorial Trillas. Primera edición. México, DF. 208 p.
Sahagún, C. J. 1990. Utilidad del análisis de varianza en el estudio de la interacción entre genotipos y ambientes. Xilonen. 1(1):21-32.
Sahagún, C. J. y Frey, K. J. 1990. Eficiencia de tres diseños experimentales para la evaluación de genotipos. Revista Chapingo. 71-72:114-122.
Sahagún, J. J. 1997. Estimación de varianzas genéticas con machos S0 y líneas hembras S1 en el Diseño II. Rev. Chapingo Ser. Hortic. 3(2):71-76.
Sahagún, C. J. 1998. Construcción y análisis de los modelos fijos, aleatorios y mixtos. Universidad Autónoma Chapingo (UACH). Departamento de Fitotecnia. Boletín técnico núm. 2. 65 p.
Sahagún, C. J.; Martínez, G. A. y Rodríguez, P. J. E. 2008. Problemas y métodos comunes del análisis de experimentos factoriales. Rev. Chapingo Ser. Hortic. 14(2):213-222.
SAS Institute Inc. 1989. SAS/STAT User’s Guide, Version 6, Fourth Edition, Volume 1, Cary, NC, USA. 943 p.
Torres, F. J. L.; Mendoza, G. B.; Prassana, B. M.; Alvarado, G.; San Vicente, F. M. y Crossa, J. 2017. Grain yield and stability of white early maize hybrids in the highland valleys of Mexico. Crop Sci. 57(6):3002-3015.
Villa, M. A.; Herrera, L.; Díaz, I. y Sozzi, A. 2010. Análisis de varianza para diseños en parcelas subdivididas con tratamientos terciarios aleatorios y una factorial en las subparcelas. Ciencia. 18(2):126-136.
Walpole, R. E.; Myers, R. H. and Ye, K. 2012. Probability and Statistics for engineers and scientists. Prentice Hall-Pearson Education. Ninth Edition. USA. 791 p.
